90SB0C70-M0UAY0 ASUS Micro-ATX Single V (LGA 1700) 4 DIMM Slots Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for 90SB0C70-M0UAY0 and save cash:

Quantity	Unit price
To 9	€468.00
To 19	€445.00 €468.00 (4.91% saved)
To 49	€436.00 €468.00 (6.84% saved)
From 50	€422.00 €468.00 (9.83% saved)

See all Single CPU (UP) Motherboards

See other ASUS products

€468.00

In stock

Happyware Article Number:

SH8M6612-971241

Manufacturer Number:

90SB0C70-M0UAY0

Brand:

ASUS

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

90SB0C70-M0UAY0

Micro-ATX Server Motherboard platform with DDR5 ECC memory and PCIe 5.0 expansion using the 90SB0C70-M0UAY0

The 90SB0C70-M0UAY0 is an ASUS micro-ATX server motherboard built on the Intel C262 platform for Intel Socket V (LGA1700), supporting Intel Xeon E and Pentium CPUs. It is engineered for compact edge and SMB systems where predictable thermals, controlled power envelopes, and serviceable layouts matter more than sheer socket count.

For memory, the 90SB0C70-M0UAY0 implements 4 DDR5 UDIMM slots in a dual-channel topology, enabling up to 128GB with ECC or non-ECC support depending on CPU selection. Expansion is optimized for mixed I/O and acceleration: a PCIe 5.0 x16 full-height, full-length slot supports high-throughput NICs, storage HBAs, or a GPU, complemented by a PCIe 4.0 x8 (x4 electrical) slot for additional controllers. Storage is balanced between capacity and boot performance through 8 SATA 6Gb/s ports and an M.2 (M-Key) socket wired as PCIe 4.0 x4 for NVMe caching or OS mirroring. Dual Intel I210-AT 1GbE ports plus a dedicated management interface align the board to segmented production and out-of-band control practices.

Why Choose the 90SB0C70-M0UAY0?

The 90SB0C70-M0UAY0 delivers a pragmatic density-to-performance profile for edge racks and appliance chassis, combining PCIe 5.0 headroom with dependable DDR5 ECC pathways and integrated BMC/IPMI. This architecture scales cleanly from single-purpose gateways to small virtualization hosts while keeping deployment and remote operations consistent across sites.

ASUS designs this platform around enterprise reliability, emphasizing validated component selection, clear service access, and modern data-centre management expectations such as secure TPM enablement and standardized remote console workflows.

Key Applications:

File and print services
Directory services
Lightweight virtualization
Firewall/UTM appliances
NAS and backup nodes
Lab test benches and CI nodes

At Happyware - Server Hardware you benefit from 24/7 Customer Service to support time-critical buildouts around the 90SB0C70-M0UAY0, and you can secure planning confidence with Non-Binding Offers tailored to your chassis, CPU, and storage controller requirements.

Technical details of 90SB0C70-M0UAY0

CPU Socket: V (LGA 1700)

Onboard Memory: No

RAID Support: Yes

CPU Manufacturer: Intel

CPU Supported Type: Xeon E, Pentium

Form Factor: Micro-ATX

Chipset: Intel C262

RAM Maximum Capacity: 128GB

Max RAM Frequency : 4400MHz

RAM Slots: 4 DIMM DDR5

RAM Channels: Dual-Channel

PCIe Slots: 1 PCIe 4.0 x8, 1 PCIe 5.0 x16

M.2 Slots: 1 PCIe 4.0 x4 M.2 2280, M.2 2260, M.2 2242 M-Key

Network Ports: 2 RJ45 1 Gbps

ECC Support: ECC, Non-ECC

Onboard Network: Ethernet

Onboard CPU: No

RAID Support: Yes

Onboard Graphic: Yes

Video Output: 1x VGA

USB Ports: 1x USB 2.0 header, 1x USB 3.0 Header, 3x USB 3.2 Gen 2 ports

Other Ports: 1x management, 1x VGA Port, 2x RJ-45 LAN Port, 3x USB-A 3.1 (10Gb/s)

Trusted Platform Module (TPM): Yes

Wi-Fi Support: None

Onboard Audio Chipset: No

Embedded: No

GPIO Pins: 0

Card Reader: No

How long is the Warranty and how you can get technical support for 90SB0C70-M0UAY0

Warranty:	36 months (part)
On site service:	yes
RMA Url:	https://www.asus.com/support/warranty-status-inquiry
Description:	In the event of an RMA, the item must be returned first. ASUS typically offers a replacement or repair service depending on the product and warranty terms. On-site service may be available for specific products such as Barbone/Full System. Carry-in.
