MBD-X13SCH-LN4F-O

Micro-ATX Server Motherboard platform with remote management and PCIe 5.0 expansion using the MBD-X13SCH-LN4F-O

The MBD-X13SCH-LN4F-O is a Supermicro X13 Series Micro-ATX server motherboard designed for compact edge and branch deployments that still require full enterprise manageability. Built on the Intel C266 chipset with a single LGA1700 socket, it supports Intel Xeon and Pentium processors up to 95W TDP, balancing compute density with predictable thermal behavior in short-depth chassis and appliance enclosures.

With the MBD-X13SCH-LN4F-O, the memory subsystem uses 4 DDR5 DIMM slots in dual-channel topology, supporting ECC and non-ECC configurations up to 128GB, enabling stable virtualization hosts and infrastructure services with controlled latency. For I/O, a PCIe 5.0 x16 slot provides a high-bandwidth path for accelerators, high-speed NICs, or storage controllers, while additional PCIe 4.0 slots expand connectivity without consuming rack space. Storage design combines 8 SATA III ports for bulk capacity and 2 PCIe 4.0 x4 M.2 NVMe sockets for OS, caching, or high-IOPS application tiers.

Why Choose the MBD-X13SCH-LN4F-O?

The MBD-X13SCH-LN4F-O delivers an efficient density-to-performance profile for remote sites by unifying compute, storage, and four Intel I210 1GbE ports on a serviceable Micro-ATX footprint. Integrated IPMI/BMC and AMI UEFI reduce hands-on operations, while TPM 2.0 support and RAID capabilities align the platform with secure, repeatable enterprise rollouts and long-lived lifecycle planning.

Supermicro engineering emphasizes validated server-grade power delivery, disciplined firmware management, and platform consistency to meet modern data center standards for reliability, remote serviceability, and controlled component interoperability.

Key Applications:

Edge and branch virtualization
AD/DNS and infrastructure services
Firewall, routing, IDS/IPS appliances
Web and middleware servers
Small database deployments

At Happyware - Server Hardware you benefit from non-binding offers tailored to your deployment plan for the MBD-X13SCH-LN4F-O, and the option to extend the warranty up to 6 years to protect long-term edge and branch infrastructure investments.

Technical details of MBD-X13SCH-LN4F-O

CPU Socket:

V (LGA 1700)

Onboard Memory:

RAID Support:

Yes

CPU Manufacturer:

Intel

CPU Supported Type:

Pentium Xeon

Form Factor:

Micro-ATX

Chipset:

Intel C266

RAM Maximum Capacity:

128GB

Max RAM Frequency :

4400MHz

RAM Slots:

4 DIMM DDR5

RAM Channels:

Dual-Channel

PCIe Slots:

1 PCIe 5.0 x16 2 PCIe 4.0 x8

M.2 Slots:

2 PCIe 4.0 x4 M.2 22110/2280 M-Key

Network Ports:

4 RJ45 1 Gbps

ECC Support:

ECC Non-ECC

Onboard Network:

Ethernet

Onboard CPU:

RAID Support:

Yes

Onboard Graphic:

Yes

Video Output:

1x VGA

USB Ports:

2x USB 3.2 Gen 1 Type-A 1x USB 3.2 Gen 1 Type-A 4x USB 2.0 header 2x USB 2.0 Type-A

Trusted Platform Module (TPM):

Yes

BIOS:

AMI UEFI

Wi-Fi Support:

None

Embedded:
