MBD-X11SSM-O Supermicro Micro-ATX Single H4 (LGA 1151) 4 DIMM Slots Server Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for MBD-X11SSM-O and save cash:

Quantity	Unit price
To 9	€282.00
To 19	€268.00 €282.00 (4.96% saved)
To 49	€263.00 €282.00 (6.74% saved)
From 50	€254.00 €282.00 (9.93% saved)

Product line:

X11

See all Single CPU (UP) Motherboards

See other Supermicro products

€282.00

In stock

Happyware Article Number:

SH3M8294-852363

Manufacturer Number:

MBD-X11SSM-O

Brand:

Supermicro

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

MBD-X11SSM-O

High-Performance Micro-ATX Server Motherboard for LGA1151 Edge Platforms with the MBD-X11SSM-O

The MBD-X11SSM-O is a Micro-ATX server motherboard built on the Intel C236 chipset for single-socket LGA1151 deployments, aligning with Xeon E3 and compatible Core, Pentium, and Celeron processors for cost-controlled branch and appliance infrastructures. Its platform design prioritises deterministic performance and low operational complexity where dedicated services, light virtualisation, or storage-focused nodes must remain stable under continuous load.

For memory integrity, the MBD-X11SSM-O implements dual-channel DDR4 with ECC UDIMM support across 4 DIMM slots, enabling balanced capacity scaling for directory services, print, and small VM consolidation. PCIe 3.0 expansion provides multiple full-height, full-length slot options to attach RAID HBAs, NICs, or accelerator-class I/O where bandwidth predictability matters more than GPU density. Storage architecture is optimised for SATA-centric builds via 8x SATA III 6Gb/s ports, supporting software RAID strategies and straightforward drive population in compact chassis. Dual Intel I210-AT 1GbE interfaces deliver reliable network behaviour and broad driver support across enterprise operating systems.

Why Choose the MBD-X11SSM-O?

The MBD-X11SSM-O offers an efficient density-to-performance profile for edge and small-server roles, combining ECC memory capability, enterprise-grade Intel networking, and practical PCIe 3.0 expansion in a Micro-ATX footprint. It is well suited for standardised rollouts where predictable I/O, service continuity, and simple maintenance take priority over integrated remote management.

Supermicro engineering focuses on long-life platform stability, validated component selection, and alignment with modern data centre integration practices. With the MBD-X11SSM-O, architects can deploy a proven Intel C236 foundation that supports security integration via TPM and chassis intrusion features for controlled environments.

Key Applications:

Edge and branch office infrastructure
Directory and print services
Small VM consolidation
SATA-based storage servers
Dedicated network and security appliances

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your MBD-X11SSM-O deployment plan and the option to extend the warranty up to 6 years for additional security on your infrastructure investment.

Technical details of MBD-X11SSM-O

CPU Socket: H4 (LGA 1151)

Onboard Memory: No

RAID Support: Yes

CPU Manufacturer: Intel

CPU Supported Type: Pentium, Celeron, Xeon, Core

Form Factor: Micro-ATX

Chipset: Intel C236

RAM Maximum Capacity: 64GB

Max RAM Frequency : 2400MHz

RAM Slots: 4 DIMM DDR4

RAM Channels: Dual-Channel

PCIe Slots: 1 PCIe 3.0 x8, 1 PCIe 3.0 x16, 2 PCIe 3.0 x8

Network Ports: 2 RJ45 1 Gbps

ECC Support: ECC

Onboard Network: Ethernet

Suitability: Server

Onboard CPU: No

RAID Support: Yes

Onboard Graphic: Yes

Video Output: 1x VGA

USB Ports: 1x USB 3.0 Type-A, 2x USB 2.0 Type-A, 2x USB 3.0 Type-A, 4x USB 2.0 Type-A

Other Ports: 2x COM Ports

Trusted Platform Module (TPM): Yes

BIOS: AMI UEFI

Wi-Fi Support: None

Bluetooth integrated: None

Onboard Audio Chipset: No

Embedded: No

GPIO Pins: 0

Card Reader: No

How long is the Warranty and how you can get technical support for MBD-X11SSM-O

Warranty:	12 months (part) 36 months (labor)
Advanced replacement:	yes
RMA Url:	https://www.supermicro.com/en/support/rma/
Description:	120 days Advance Cross-Ship
