90MB1F40-M0EAY0 ASUS Micro-ATX Single AM5 2 DIMM Slots Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for 90MB1F40-M0EAY0 and save cash:

Quantity	Unit price
To 19	€132.00
To 49	€122.00 €132.00 (7.58% saved)
To 99	€113.00 €132.00 (14.39% saved)
From 100	€106.00 €132.00 (19.7% saved)

Product line:

ASUS Prime

See other ASUS products

€132.00

In stock

Happyware Article Number:

SH4M9496-368484

Manufacturer Number:

90MB1F40-M0EAY0

Brand:

ASUS

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

90MB1F40-M0EAY0

Micro-ATX AM5 Desktop Motherboard optimised for efficient DDR5 and PCIe 4.0 I/O with the 90MB1F40-M0EAY0

The 90MB1F40-M0EAY0 is an ASUS Prime A620M-K Micro-ATX platform designed around the AMD A620 chipset and AM5 Ryzen desktop CPUs, delivering a balanced foundation for cost-controlled office systems, edge nodes, and general productivity builds. It supports Ryzen processors up to 120W TDP and pairs them with a dual-channel DDR5 memory subsystem using 2 DIMM slots, enabling up to 96GB capacity for responsive multitasking and light content workflows without overprovisioning.

For I/O scalability, the 90MB1F40-M0EAY0 provides a PCIe 4.0 x16 slot for a discrete GPU, accelerator card, or high-bandwidth adapter, complemented by a PCIe 3.0 x1 slot for incremental expansion. Storage architecture is split between a PCIe 4.0 M.2 (M-Key) path for low-latency NVMe boot or application tiers and 4 SATA III ports with RAID support for capacity-oriented arrays, making the board suitable for small datasets, local caching, and structured file storage.

Why Choose the 90MB1F40-M0EAY0?

The 90MB1F40-M0EAY0 targets practical density-to-performance for AM5 deployments where stable DDR5 operation, predictable PCIe 4.0 connectivity, and straightforward integration matter more than remote management features. It is well suited for standardized fleets, lab benches, or edge cabinets that rely on UEFI-based provisioning and TPM-backed platform security, while keeping the bill of materials and operational complexity under control.

ASUS engineering emphasizes long-term platform consistency, validated component interoperability, and firmware maturity aligned with modern OS and security baselines. With a conventional desktop management model (no IPMI/BMC), the design fits environments where local console access and controlled imaging pipelines are the norm.

Key Applications:

SMB office desktops and productivity endpoints
Light content creation workstations
Edge compute nodes without IPMI requirements
Home lab virtualization and test benches
NVMe + SATA hybrid storage builds

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your needs and the option to extend the warranty up to 6 years, supporting predictable procurement and long-term lifecycle planning for 90MB1F40-M0EAY0-based deployments.

Technical details of 90MB1F40-M0EAY0

CPU Socket: AM5

RAID Support: Yes

CPU Manufacturer: AMD

CPU Supported Type: Ryzen

Form Factor: Micro-ATX

Chipset: AMD A620

RAM Maximum Capacity: 96GB

Max RAM Frequency : 7200MHz

RAM Slots: 2 DIMM DDR5

RAM Channels: Dual-Channel

PCIe Slots: 1 PCIe 3.0 x1, 1 PCIe 4.0 x16

M.2 Slots: 1 PCIe 4.0 M.2 2280, M.2 2260, M.2 2242 M-Key

Network Ports: 1 RJ45 1 Gbps

ECC Support: Non-ECC

Onboard Network: Ethernet

Onboard CPU: No

RAID Support: Yes

Onboard Graphic: Yes

Video Output: 1x HDMI, 1x VGA

USB Ports: 2x USB 2.0 Type-A, 4x USB 3.2 Gen 1 Type-A

Other Ports: 1x PS/2 Combo, 1x RJ-45 LAN Port, 3x audio jacks

Trusted Platform Module (TPM): Yes

BIOS: AMI UEFI

Wi-Fi Support: None

Onboard Audio Chipset: Realtek ALC897

Embedded: No

How long is the Warranty and how you can get technical support for 90MB1F40-M0EAY0

Warranty:	36 months (part)
On site service:	yes
RMA Url:	https://www.asus.com/support/warranty-status-inquiry
Description:	In the event of an RMA, the item must be returned first. ASUS typically offers a replacement or repair service depending on the product and warranty terms. On-site service may be available for specific products such as Barbone/Full System. Carry-in.
