G493-SB1-AAP1 Gigabyte Dual Xeon Scalable 4th Gen 4U 6NG493SB1DR000ABP1 Server Barebone

Product line:

Gigabyte G Series

See all Rackmount Servers 4U

See other Gigabyte products

€12,900.00

Out of stock

Not available

Happyware Article Number:

SH1B5231-377756

Manufacturer Number:

6NG493SB1DR000ABP1

Brand:

Gigabyte

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

G493-SB1-AAP1 Gigabyte

High-Density 4U GPU Server Barebone engineered for PCIe Gen5 acceleration with the G493-SB1-AAP1 Gigabyte

The G493-SB1-AAP1 Gigabyte is a 4U rack GPU server barebone designed for multi-GPU AI and HPC clusters that require high PCIe Gen5 lane availability and consistent airflow at scale. Built on the Intel C741 platform with dual Intel Xeon Scalable 4th/5th Gen (LGA4677), it supports up to 350W CPUs to sustain heavy GPU feeding, memory bandwidth, and parallel job scheduling under mixed training and inference duty cycles.

For memory-bound workloads, G493-SB1-AAP1 Gigabyte provides DDR5 ECC RDIMM with 32 DIMM slots and 8 channels per CPU, enabling high-capacity configurations up to 8TB for large models, in-memory analytics, and simulation. Expansion is optimized around 10 PCIe 5.0 x16 FHFL GPU slots plus 2 PCIe 5.0 x16 LP slots, allowing dense accelerators alongside high-speed fabrics or storage controllers. The storage plane supports 12 hot-swap 2.5"/3.5" bays with NVMe (PCIe Gen5 x4), SAS-4, or SATA, complemented by an M.2 NVMe boot device to separate OS from data paths and reduce service impact.

Why Choose the G493-SB1-AAP1 Gigabyte?

The G493-SB1-AAP1 Gigabyte targets enterprises standardizing on repeatable GPU nodes where predictable PCIe topology, redundant power, and remote management simplify fleet operations. Its density-to-performance profile fits scale-out training pods and HPC partitions, while dual-socket compute and high DIMM count support balanced CPU/GPU utilization and resilient scheduling as configurations evolve.

Gigabyte designs this platform around serviceability and data centre alignment, combining hot-swap drive bays, 4x 3000W redundant Titanium PSUs, and ASPEED AST2600 BMC management with IPMI and HTML5 KVM for lights-out provisioning and lifecycle control.

Key Applications:

AI training clusters
AI inference acceleration
HPC and scientific simulation
Visual computing and rendering
Advanced analytics

At Happyware - Server Hardware you benefit from non-binding offers tailored to your G493-SB1-AAP1 Gigabyte rollout and the option to extend the warranty up to 6 years for long-term operational assurance in production GPU environments.

Technical details of G493-SB1-AAP1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

E (LGA 4677)

CPU Family:

Xeon

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon Scalable 5th Gen Xeon Scalable 4th Gen

Supported CPU Generation:

4th 5th

Supported CPU Codename:

Emerald Rapids Sapphire Rapids

Nodes:

RAM Type:

RDIMM

RAM Max. Total:

8TB

RAM Slots Total:

ECC Support:

ECC

Bays:

12x 2.5"/3.5" HotSwap NVMe, SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

10x PCIe 5.0 x16 (x16 mode) 2x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

10x PCIe 5.0 x16 Full-Height Full-Length (Standard) 2x PCIe 5.0 x16 Low-Profile

Onboard Network LAN:

2x RJ45 10 Gbps Intel X710-AT2

Onboard Network LAN Speed:

10 Gbps

Front I/O Ports:

VGA NMI button System status LED Storage Activity LED Power button with LED USB UID button with LED

IPMI / BMC integrated:

Yes

Chipset:

Intel C741

Power Supply Wattage:

3000W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Quantity of Cooler:

Performance Class:

High-End

TDP (Thermal Design Power):

350W

Applications:

AI/Deep Learning AI Inference Visual Computing GPU Server Machine Learning (ML) High-Performance Computing (HPC)

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

Supported GPU Type:

PCIe

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Certificates:

80 Plus Titanium

Chassis Intrusion:

OS:

Citrix Hypervisor (formerly XenServer) Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C

How long is the Warranty and how you can get technical support for G493-SB1-AAP1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
