90SB09X0-M1UAY0 ASUS Micro-ATX Single H5 (LGA 1200) 4 DIMM Slots Workstation Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for 90SB09X0-M1UAY0 and save cash:

Quantity	Unit price
To 9	€389.00
To 19	€370.00 €389.00 (4.88% saved)
To 49	€362.00 €389.00 (6.94% saved)
From 50	€351.00 €389.00 (9.77% saved)

See all Single CPU (UP) Motherboards

See other ASUS products

€389.00

In stock

Happyware Article Number:

SH5M9104-744459

Manufacturer Number:

90SB09X0-M1UAY0

Brand:

ASUS

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

90SB09X0-M1UAY0

High-Performance Micro-ATX Server/Workstation Motherboard featuring Intel C252 platform with the 90SB09X0-M1UAY0

The 90SB09X0-M1UAY0 is an ASUS Micro-ATX server/workstation motherboard designed for compact edge servers and SMB infrastructure where predictable validation matters. Built on the Intel C252 platform with an Intel LGA1200 socket, it supports Intel Xeon E and Pentium processors to balance single-socket efficiency with enterprise manageability for entry virtualization, light private cloud nodes, and general-purpose workstation builds.

For memory architecture, the 90SB09X0-M1UAY0 provides dual-channel DDR4 with 4 DIMM slots and up to 128GB capacity, enabling ECC or non-ECC operation depending on CPU selection—useful for tuning reliability versus cost in mixed-purpose deployments. PCIe Gen4 expansion is addressed through a full-height x16 slot and a second full-height x8 slot (x4 electrical), allowing practical integration of high-throughput NICs, storage HBAs, or accelerators without over-subscribing lanes. Storage design centers on 6 SATA 6Gb/s ports for RAID-capable arrays plus an M.2 (M-Key) PCIe Gen3 slot for NVMe boot or cache, aligning the platform for NAS/backup roles and latency-sensitive OS placement.

Why Choose the 90SB09X0-M1UAY0?

The 90SB09X0-M1UAY0 delivers a strong density-to-performance ratio by combining server-grade management with a space-efficient Micro-ATX footprint suited to short-depth chassis and remote sites. Integrated IPMI/BMC, TPM support, and validated I/O simplify secure provisioning, monitoring, and lifecycle control, while dual Intel I210-AT 1GbE ports support stable baseline connectivity and predictable driver behavior across enterprise images.

ASUS engineering emphasizes platform stability, component-level qualification, and long-term operability aligned with modern data centre standards, including remote manageability and consistent firmware servicing. With the 90SB09X0-M1UAY0, system builders can standardize on a single-socket architecture that scales across edge, lab, and branch deployments.

Key Applications:

Edge servers and SMB infrastructure
Entry virtualization and light private cloud
NAS and backup appliances
General-purpose workstation builds

At Happyware - Server Hardware you benefit from non-binding offers tailored to your deployment and bill-of-material requirements, helping you standardize configurations around the 90SB09X0-M1UAY0 with minimal procurement friction. For rollouts across multiple sites, bulk order discount options support consistent platform adoption at scale.

Technical details of 90SB09X0-M1UAY0

CPU Socket:

H5 (LGA 1200)

Onboard Memory:

RAID Support:

Yes

CPU Manufacturer:

Intel

CPU Supported Type:

Xeon E Pentium

Form Factor:

Micro-ATX

Chipset:

Intel C252

RAM Maximum Capacity:

128GB

Max RAM Frequency :

3200MHz

RAM Slots:

4 DIMM DDR4

RAM Channels:

Dual-Channel

PCIe Slots:

1 PCIe 4.0 x8 1 PCIe 4.0 x16

M.2 Slots:

1 PCIe Gen 3 M.2 2280/2260/2242 M-Key

Network Ports:

2 RJ45 1 Gbps

ECC Support:

ECC Non-ECC

Onboard Network:

Ethernet

Suitability:

Server Workstation

Onboard CPU:

RAID Support:

Yes

Onboard Graphic:

Yes

Video Output:

1x HDMI 1.4 1x VGA

USB Ports:

2x USB 3.2 Gen 2 Type-A 2x USB 2.0 Type-A

Trusted Platform Module (TPM):

Yes

Onboard Audio Chipset:

Embedded:

How long is the Warranty and how you can get technical support for 90SB09X0-M1UAY0

Warranty:	36 months (part)
On site service:	yes
RMA Url:	https://www.asus.com/support/warranty-status-inquiry
Description:	In the event of an RMA, the item must be returned first. ASUS typically offers a replacement or repair service depending on the product and warranty terms. On-site service may be available for specific products such as Barbone/Full System. Carry-in.
