MBD-X8SIA-F-B Supermicro ATX Single H/H1 (LGA 1156) 6 DIMM Slots Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for MBD-X8SIA-F-B and save cash:

Quantity	Unit price
To 9	€302.71
To 19	€287.76 €302.71 (4.94% saved)
To 49	€281.76 €302.71 (6.92% saved)
From 50	€272.66 €302.71 (9.93% saved)

Product line:

X8 Series

See all Single CPU (UP) Motherboards

See other Supermicro products

€302.71

Out of stock

Not available

Happyware Article Number:

SH8M1400-639475

Manufacturer Number:

MBD-X8SIA-F-B

Brand:

Supermicro

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

MBD-X8SIA-F-B

High-Performance ATX Server Motherboard featuring Intel 3420 LGA1156 platform management with the MBD-X8SIA-F-B

The MBD-X8SIA-F-B is an ATX server motherboard engineered around the Intel 3420 chipset and LGA1156 CPU ecosystem, enabling cost-controlled deployments for Xeon and compatible Core i3/Pentium/Celeron processors. This platform targets stable single-socket infrastructure where predictable thermals, validated firmware, and remote manageability are required for branch and SMB environments.

The MBD-X8SIA-F-B implements DDR3 ECC DIMM memory across 6 slots, supporting up to 32GB at up to 1333 MT/s to balance capacity, error correction, and service continuity. For I/O growth, the MBD-X8SIA-F-B provides PCIe 2.0 and PCIe 1.0 expansion options to accommodate RAID HBAs, additional NICs, and security appliances without forcing a chassis redesign. Dual Intel 82574L 1GbE interfaces align with segmented LAN/WAN topologies, while onboard VGA simplifies initial provisioning. Integrated IPMI/BMC remote management on the MBD-X8SIA-F-B enables lights-out operations, reducing on-site intervention for edge nodes and small server rooms.

Why Choose the MBD-X8SIA-F-B?

The MBD-X8SIA-F-B delivers a practical density-to-performance profile for single-socket services by combining ECC memory, flexible PCIe expansion, and IPMI-driven operational control. It is well suited to standardized rollouts where repeatable configuration, uptime-focused component selection, and straightforward scalability through add-in cards are more valuable than peak compute.

Supermicro designs platforms with an emphasis on enterprise reliability, long-life component sourcing, and management consistency across deployments. The board architecture aligns with data centre operational standards by prioritizing remote diagnostics, stable I/O, and predictable integration into existing rack and edge environments.

Key Applications:

SMB file and print servers
Directory and authentication services
Firewall and routing appliances
Lightweight virtualization hosts
Branch office managed nodes via IPMI

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your rollout requirements and an extended warranty up to 6 years to protect long-lived infrastructure investments built on the MBD-X8SIA-F-B.

Technical details of MBD-X8SIA-F-B

CPU Socket:

H/H1 (LGA 1156)

Onboard Memory:

RAID Support:

Yes

CPU Manufacturer:

Intel

CPU Supported Type:

Core i3 Pentium Celeron Xeon

Form Factor:

ATX

Chipset:

Intel 3420

RAM Maximum Capacity:

32GB

Max RAM Frequency :

1333MHz

RAM Slots:

6 DIMM DDR3

RAM Channels:

Triple-Channel

PCIe Slots:

1 PCIe 2.0 x8 2 PCIe 1.0 x1 3 PCIe 2.0 x16

Network Ports:

2 RJ45 1 Gbps

ECC Support:

ECC

Onboard Network:

Ethernet

Onboard CPU:

RAID Support:

Yes

Onboard Graphic:

Yes

Video Output:

1x VGA

USB Ports:

4x USB 2.0 Type-A 6x USB 2.0 Type-A

BIOS:

AMI UEFI

Wi-Fi Support:

None

Embedded:

How long is the Warranty and how you can get technical support for MBD-X8SIA-F-B

Warranty:	12 months (part) 36 months (labor)
Advanced replacement:	yes
RMA Url:	https://www.supermicro.com/en/support/rma/
Description:	120 days Advance Cross-Ship
