90MB1IT0-M0EAY0 ASUS ATX Single AM5 4 DIMM Slots Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for 90MB1IT0-M0EAY0 and save cash:

Quantity	Unit price
To 9	€290.00
To 19	€276.00 €290.00 (4.83% saved)
To 49	€270.00 €290.00 (6.9% saved)
From 50	€261.00 €290.00 (10% saved)

Product line:

Prime

See all Server Motherboards

See other ASUS products

€290.00

In stock

Happyware Article Number:

SH3M2365-181682

Manufacturer Number:

90MB1IT0-M0EAY0

Brand:

ASUS

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

90MB1IT0-M0EAY0

ATX AMD X870 Workstation and Edge Platform Motherboard with PCIe 5.0 Expansion using the 90MB1IT0-M0EAY0

The 90MB1IT0-M0EAY0 is an ASUS ATX motherboard built on the AMD X870 chipset for the AM5 Ryzen desktop platform, targeting workstation-class builds and compact edge or SMB server roles where standard remote management is not required. It provides a balanced CPU platform foundation with modern I/O, enabling high-throughput GPU and NVMe configurations for engineering, content creation, and developer virtualization.

With the 90MB1IT0-M0EAY0, memory architecture centers on a 4-DIMM dual-channel DDR5 layout up to 192GB, supporting both ECC and non-ECC modules to align reliability with performance profiles. Expansion is optimized around a PCIe 5.0 x16 full-length slot for accelerators, complemented by additional full-length PCIe 4.0 slots for capture, NICs, or specialized I/O. Storage design emphasizes tiered NVMe: a primary PCIe 5.0 x4 M.2 for peak bandwidth alongside PCIe 4.0 and PCIe 3.0 M.2 options, plus SATA III for capacity and legacy devices, with RAID-capable configurations for resilient local datasets.

Why Choose the 90MB1IT0-M0EAY0?

The 90MB1IT0-M0EAY0 delivers a practical density-to-performance ratio for GPU-enabled workstations and edge nodes by combining PCIe 5.0 bandwidth, multiple NVMe domains, and DDR5 capacity headroom in a standard ATX footprint. It supports scalable builds that can evolve from developer desktops to small departmental servers while retaining enterprise-focused reliability features such as TPM integration and robust firmware recovery options.

ASUS engineers this platform with an emphasis on stable power delivery, predictable firmware behavior, and broad peripheral interoperability, aligning the 90MB1IT0-M0EAY0 with modern data centre standards for secure boot chains, storage flexibility, and repeatable deployment across fleets.

Key Applications:

Engineering CAD and simulation workstations
Content creation and rendering pipelines
Developer desktop virtualization hosts
Edge analytics and small office servers
High-speed NVMe build and test environments

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your deployment plan for the 90MB1IT0-M0EAY0, plus extended warranty options up to 6 years to secure long lifecycle operation in professional environments.

Technical details of 90MB1IT0-M0EAY0

CPU Socket:

AM5

RAID Support:

Yes

CPU Manufacturer:

AMD

CPU Supported Type:

Ryzen

Form Factor:

ATX

Chipset:

AMD X870

RAM Maximum Capacity:

192GB

Max RAM Frequency :

8000MHz

RAM Slots:

4 DIMM DDR5

RAM Channels:

Dual-Channel

PCIe Slots:

1 PCIe 5.0 x16 2 PCIe 4.0 x16

M.2 Slots:

1 PCIe 3.0 M.2 2280 M-Key 1 PCIe 4.0 M.2 2280 M-Key 1 PCIe 4.0 M.2 2280/2260/2242 M-Key 1 PCIe 5.0 M.2 2280 M-Key

Network Ports:

1 RJ45 2.5 Gbps

ECC Support:

ECC Non-ECC

Onboard Network:

Ethernet

RAID Support:

Yes

Onboard Graphic:

Yes

Video Output:

2x DisplayPort 1.4a 1x HDMI 2.1

USB Ports:

2x USB 3.2 Gen 1 Header 1x USB 3.2 Gen 2 1x USB 3.2 Gen 2 Header 3x USB 3.2 Gen 1 2x USB4.0 Type-C 4x USB 2.0 header 4x USB 2.0

Other Ports:

1x serial - header 1x SPDIF-Header 1x COM Debug-Header 1x TPM Header

Trusted Platform Module (TPM):

Yes

BIOS:

AMI UEFI

Wi-Fi Support:

None

Onboard Audio Chipset:

Realtek ALC887

Embedded:

How long is the Warranty and how you can get technical support for 90MB1IT0-M0EAY0

Warranty:	36 months (part)
On site service:	yes
RMA Url:	https://www.asus.com/support/warranty-status-inquiry
Description:	In the event of an RMA, the item must be returned first. ASUS typically offers a replacement or repair service depending on the product and warranty terms. On-site service may be available for specific products such as Barbone/Full System. Carry-in.
