90MB1HN0-M0EAY0 ASUS Micro-ATX Single V (LGA 1700) 2 DIMM Slots Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for 90MB1HN0-M0EAY0 and save cash:

Quantity	Unit price
To 19	€126.00
To 49	€116.00 €126.00 (7.94% saved)
To 99	€108.00 €126.00 (14.29% saved)
From 100	€101.00 €126.00 (19.84% saved)

Product line:

Prime

See other ASUS products

€126.00

In stock

Happyware Article Number:

SH0M8646-874688

Manufacturer Number:

90MB1HN0-M0EAY0

Brand:

ASUS

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

90MB1HN0-M0EAY0

Micro-ATX Intel H610 Desktop Motherboard for compact business systems with the 90MB1HN0-M0EAY0

The 90MB1HN0-M0EAY0 is a Micro-ATX motherboard built on the Intel H610 chipset for the LGA1700 desktop platform, enabling cost-controlled deployments with modern Intel Core or Celeron processors up to 125W. It targets office PCs, entry workstations, and lab benches where predictable platform behaviour, broad peripheral compatibility, and straightforward serviceability matter more than premium overclocking features.

With dual-channel DDR4 via 2 DIMM slots up to 64GB, the 90MB1HN0-M0EAY0 balances memory capacity and BOM efficiency for productivity and light content creation. Expansion is designed around clear lane allocation: a PCIe 4.0 x16 slot supports a discrete GPU or accelerator-class card in full-height form factors, complemented by a PCIe 3.0 x1 slot for add-in I/O. Storage architecture combines a PCIe Gen3 NVMe M.2 socket for low-latency boot and application volumes with 4 SATA 6Gb/s ports for capacity tiers. Integrated 1GbE, HDMI 2.1 plus VGA, serial, PS/2, and mixed USB 2.0/USB 3.2 Gen1 provide broad connectivity for mixed-generation peripherals and edge control nodes.

Why Choose the 90MB1HN0-M0EAY0?

The 90MB1HN0-M0EAY0 delivers an efficient density-to-performance profile for compact enclosures and standardized fleet builds, pairing PCIe 4.0 graphics capability with pragmatic DDR4 and Gen3 NVMe. It is well-suited for scalable rollouts where consistent BIOS configuration, stable drivers, and straightforward I/O mapping reduce integration time and support overhead.

ASUS engineering emphasizes platform validation, firmware maturity, and compatibility alignment with current data centre and enterprise endpoint standards. The 90MB1HN0-M0EAY0 integrates AMI UEFI BIOS and TPM support to fit managed environments that require repeatable provisioning and baseline security without BMC/IPMI complexity.

Key Applications:

Office productivity desktops
Entry-level workstation builds
Edge control and automation nodes
Lab validation and test benches
Digital signage and kiosk systems

At Happyware - Server Hardware you benefit from non-binding offers tailored to your 90MB1HN0-M0EAY0 rollout and component bill-of-materials, plus bulk order discount options for standardized multi-site deployments.

Technical details of 90MB1HN0-M0EAY0

CPU Socket: V (LGA 1700)

Onboard Memory: No

RAID Support: No

CPU Manufacturer: Intel

CPU Supported Type: Celeron, Core

Form Factor: Micro-ATX

Chipset: Intel H610

RAM Maximum Capacity: 64GB

Max RAM Frequency : 3200MHz

RAM Slots: 2 DIMM DDR4

RAM Channels: Dual-Channel

PCIe Slots: 1 PCIe 3.0 x1, 1 PCIe 4.0 x16

M.2 Slots: 1 PCIe 3.0 M.2 2280, M.2 2260, M.2 2242 M-Key

Network Ports: 1 RJ45 1 Gbps

ECC Support: Non-ECC

Onboard Network: Ethernet

Onboard CPU: No

RAID Support: No

Onboard Graphic: Yes

Video Output: 1x HDMI 2.1, 1x VGA

USB Ports: 1x USB 2.0 header, 1x USB 3.2 Gen 1 Header, 2x USB 3.2 Gen 1 Type-A, 4x USB 2.0 Type-A

Other Ports: 1x PS/2 Combo, 1x Serial Ports, 3x Audio Port

Trusted Platform Module (TPM): Yes

BIOS: AMI UEFI

Wi-Fi Support: None

Onboard Audio Chipset: Realtek ALC897

Embedded: No

Card Reader: No

How long is the Warranty and how you can get technical support for 90MB1HN0-M0EAY0

Warranty:	36 months (part)
On site service:	yes
RMA Url:	https://www.asus.com/support/warranty-status-inquiry
Description:	In the event of an RMA, the item must be returned first. ASUS typically offers a replacement or repair service depending on the product and warranty terms. On-site service may be available for specific products such as Barbone/Full System. Carry-in.
