90MB1G50-M0EAY0 ASUS Micro-ATX Single V (LGA 1700) 4 DIMM Slots Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for 90MB1G50-M0EAY0 and save cash:

Quantity	Unit price
To 9	€262.22
To 19	€249.20 €262.22 (4.97% saved)
To 49	€243.90 €262.22 (6.99% saved)
From 50	€236.00 €262.22 (10% saved)

Product line:

TUF Gaming

See all ASUS

See other ASUS products

€262.22

In stock

Happyware Article Number:

SH9M5823-535439

Manufacturer Number:

90MB1G50-M0EAY0

Brand:

ASUS

Are you a reseller?

Do you have questions about this product 90MB1G50-M0EAY0?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

90MB1G50-M0EAY0

High-Performance Micro-ATX Intel LGA1700 Motherboard featuring PCIe Gen4 storage expansion with the 90MB1G50-M0EAY0

The 90MB1G50-M0EAY0 is a Micro-ATX motherboard built on the Intel B760 chipset for the LGA1700 desktop platform, targeting compact workstation, lab, and edge deployments where I/O density and deterministic behavior matter more than remote BMC management. It supports 12th/13th Gen class Intel Core processors, enabling balanced CPU compute for general productivity, content creation, and development benches.

Memory is provisioned via dual-channel DDR5 across 4 DIMM slots, scaling to 192GB and supporting high transfer rates for bandwidth-sensitive workflows and multi-VM test rigs. For storage architecture, the 90MB1G50-M0EAY0 provides 3 PCIe Gen4 x4 M.2 sockets plus 4 SATA 6Gb/s ports with RAID support, allowing separation of OS, scratch, and dataset tiers without saturating shared lanes. Expansion and peripheral connectivity are aligned to modern client platforms, with robust rear and internal USB including USB 3.2 Gen2x2 Type-C, while integrated networking combines 2.5GbE and Wi‑Fi 6 with Bluetooth 5.2 for flexible placement.

Why Choose the 90MB1G50-M0EAY0?

The 90MB1G50-M0EAY0 offers an efficient density-to-performance profile for space-constrained builds, delivering DDR5 capacity headroom and PCIe Gen4 NVMe scaling in a Micro-ATX footprint. It is suited to standardized rollouts where reliability, repeatable firmware behavior via AMI UEFI BIOS, and predictable expansion paths are required, while accepting that out-of-band management is not integrated.

ASUS designs this platform with a pragmatic engineering focus on electrical stability, validated compatibility, and sustained operation under mixed I/O loads, aligning with contemporary data centre and lab standards for cabling, PCIe storage, and high-speed USB connectivity.

Key Applications:

Compact workstation builds
Content creation and media pipelines
Edge compute and branch-office systems
Development and validation test benches
High-I/O desktop virtualization labs

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your deployment requirements for the 90MB1G50-M0EAY0, and an extended warranty of up to 6 years to secure lifecycle planning and fleet consistency.

Technical details of 90MB1G50-M0EAY0

CPU Socket:

V (LGA 1700)

Onboard Memory:

RAID Support:

Yes

CPU Manufacturer:

Intel

CPU Supported Type:

Core i9 Core i7 Core i5 Core i3 Pentium Gold Celeron

Form Factor:

Micro-ATX

Chipset:

Intel B760

RAM Maximum Capacity:

192GB

Max RAM Frequency :

7200MHz

RAM Slots:

4 DIMM DDR5

RAM Channels:

Dual-Channel

M.2 Slots:

1 PCIe Gen 4 M.2 2280 M-Key 1 WiFi+BT-Modul M.2 2230 E-Key 2 PCIe Gen 4 M.2 2280/2260/2242 M-Key

Network Ports:

1 RJ45 2.5 Gbps

ECC Support:

Non-ECC

Onboard Network:

Ethernet

Onboard CPU:

RAID Support:

Yes

Onboard Graphic:

Yes

Video Output:

1x DisplayPort 1x HDMI

USB Ports:

1x USB 3.2 Gen 2 Type-C 4x USB 2.0 Type-A 2x USB 3.2 Gen 2 Type-A 2x USB 3.2 Gen 1 Type-A 3x USB 3.2 Gen 1 Type-A 1x USB 3.2 Gen 2x2 Type-C

BIOS:

AMI UEFI

Wi-Fi Support:

Wi-Fi 6 (802.11ax)

Bluetooth integrated:

5.2

Onboard Audio Chipset:

Realtek ALC897

Embedded:

Card Reader:

How long is the Warranty and how you can get technical support for 90MB1G50-M0EAY0

Warranty:	36 months (part)
On site service:	yes
RMA Url:	https://www.asus.com/support/warranty-status-inquiry
Description:	In the event of an RMA, the item must be returned first. ASUS typically offers a replacement or repair service depending on the product and warranty terms. On-site service may be available for specific products such as Barbone/Full System. Carry-in.
