90MB1F60-M0EAY0 ASUS Micro-ATX Single AM5 2 DIMM Slots Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for 90MB1F60-M0EAY0 and save cash:

Quantity	Unit price
To 9	€167.00
To 19	€159.00 €167.00 (4.79% saved)
To 49	€156.00 €167.00 (6.59% saved)
From 50	€151.00 €167.00 (9.58% saved)

Product line:

ASUS Prime

See other ASUS products

€167.00

In stock

Happyware Article Number:

SH2M5981-419941

Manufacturer Number:

90MB1F60-M0EAY0

Brand:

ASUS

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

90MB1F60-M0EAY0

High-Performance Micro-ATX AM5 Motherboard Platform for DDR5 and PCIe Expansion with the 90MB1F60-M0EAY0

The 90MB1F60-M0EAY0 is an ASUS Micro-ATX motherboard built on the AMD B650 chipset for the AM5 Ryzen platform, designed as a stable base for compact workstations, entry server labs, and storage-forward builds. It pairs modern CPU support with a dual-channel DDR5 memory architecture via 2 DIMM slots, enabling predictable latency and bandwidth characteristics for general productivity, light content creation, and virtualization testbeds.

For I/O scalability, the 90MB1F60-M0EAY0 combines high-speed NVMe and bulk SATA design: 2 M.2 M-Key slots (1x PCIe Gen5, 1x PCIe Gen4) support a fast boot and application tier, while 5x SATA 6Gb/s ports provide capacity-oriented arrays with RAID support. PCIe generation coverage helps align lane budget to workload priorities, and 2.5GbE improves east-west lab traffic compared to legacy 1GbE. USB connectivity includes rear USB 3.2 Gen2 and an internal USB-C header to integrate modern peripherals and chassis front I/O.

Why Choose the 90MB1F60-M0EAY0?

The 90MB1F60-M0EAY0 delivers an efficient density-to-capability profile for teams standardizing on AM5 while keeping chassis footprint and power budgets controlled. Its balanced storage topology, 2.5GbE, and UEFI tooling support repeatable deployments, component refresh cycles, and scalable lab environments without introducing datacenter-only management dependencies.

ASUS engineering emphasizes board-level signal integrity, firmware maturity, and compatibility validation aligned with modern PSU, PCIe, and DDR5 ecosystems. The platform includes AMI UEFI features such as USB BIOS Flashback to reduce recovery time during updates and qualification iterations.

Key Applications:

General productivity workstations
Light content creation
Virtualization testbed and home lab services
NVMe boot with SATA bulk storage
Small office edge compute nodes

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your needs for integrating the 90MB1F60-M0EAY0 into standardized builds, and you can extend the warranty up to 6 years to protect long-lived lab and edge deployments.

Technical details of 90MB1F60-M0EAY0

CPU Socket: AM5

RAID Support: Yes

CPU Manufacturer: AMD

CPU Supported Type: Ryzen

Form Factor: Micro-ATX

Chipset: AMD B650

RAM Maximum Capacity: 96GB

Max RAM Frequency : 8000MHz

RAM Slots: 2 DIMM DDR5

RAM Channels: Dual-Channel

M.2 Slots: 1 PCIe 4.0 M.2 2280, M.2 2260, M.2 2242 M-Key, 1 PCIe 5.0 M.2 2280, M.2 2260, M.2 2242 M-Key

Network Ports: 1 RJ45 2.5 Gbps

ECC Support: ECC, Non-ECC, on-die ECC

Onboard Network: Ethernet

Performance Class: High performance

Onboard CPU: No

RAID Support: Yes

Onboard Graphic: Yes

Video Output: 1x HDMI 2.1, 1x VGA

USB Ports: 1x USB 3.2 Gen 1 Header, 1x USB Type-C, 2x USB 2.0 header, 2x USB 3.2 Gen 1, 2x USB 3.2 Gen 2, 4x USB 2.0

Other Ports: 1x COM Debug-Header, 1x PS/2 Combo, 1x RJ-45 LAN Port, 1x serial - header, 1x SPDIF-Header, 1x Speaker-Header, 1x TPM Header, 3x 3.5mm Klinke (Realtek ALC897)

Trusted Platform Module (TPM): Optional

BIOS: AMI UEFI

Wi-Fi Support: None

Onboard Audio Chipset: Realtek ALC897

Embedded: No

How long is the Warranty and how you can get technical support for 90MB1F60-M0EAY0

Warranty:	36 months (part)
On site service:	yes
RMA Url:	https://www.asus.com/support/warranty-status-inquiry
Description:	In the event of an RMA, the item must be returned first. ASUS typically offers a replacement or repair service depending on the product and warranty terms. On-site service may be available for specific products such as Barbone/Full System. Carry-in.
