90MB18E0-M0EAY0 ASUS ATX Single V (LGA 1700) 4 DIMM Slots Mainboard

Product line:

ROG Maximus

See other ASUS products

This product is currently not priced. Request a personalized quote now.

Out of stock

Not available

Happyware Article Number:

SH3M5934-234857

Manufacturer Number:

90MB18E0-M0EAY0

Brand:

ASUS

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

90MB18E0-M0EAY0

High-Performance ATX Workstation Motherboard Platform featuring PCIe 5.0 Expansion with the 90MB18E0-M0EAY0

The 90MB18E0-M0EAY0 is an ASUS ATX motherboard designed around the Intel Z690 chipset and LGA1700 socket for 12th Gen-era Intel Core platforms, enabling balanced CPU scalability for engineering desktops, creator workstations, and local virtualization labs. With 4 DDR5 DIMM slots in dual-channel topology up to 128GB, the 90MB18E0-M0EAY0 targets high clocked memory configurations where bandwidth and latency tuning matter more than ECC protection, aligning well with interactive CAD, compilation, and mixed productivity pipelines.

For expansion, the 90MB18E0-M0EAY0 provides a PCIe 5.0 x16 slot for next-generation GPUs and accelerator-class cards, plus additional full-height, full-length slots to accommodate capture, storage, or high-speed I/O adapters while preserving mechanical compatibility in workstation chassis. Storage architecture is optimized for tiering: multiple M.2 positions for NVMe-centric boot and scratch volumes, complemented by 6 SATA III ports for SSD/HDD arrays, making the 90MB18E0-M0EAY0 suitable for fast local datasets and resilient multi-drive layouts. Integrated 2.5GbE and Wi-Fi 6E support flexible placement across desk-side and lab environments.

Why Choose the 90MB18E0-M0EAY0?

The 90MB18E0-M0EAY0 delivers a density-to-performance profile that fits enterprise workstation standardization: PCIe 5.0 headroom for a primary GPU, strong NVMe and SATA consolidation for local storage tiers, and predictable platform behavior via AMI UEFI with BIOS Flashback for controlled fleet updates. It scales cleanly from single-GPU creator nodes to expansion-heavy engineering stations without requiring a server platform.

ASUS engineering focuses on power delivery stability, board-level signal integrity, and component validation to support sustained workloads and repeatable builds while aligning with modern security expectations through TPM support and mainstream deployment tooling.

Key Applications:

Content creation workstations
Light to medium CAD
Local virtualization labs
Single-GPU or dual-slot GPU workstations
High-speed NVMe and SATA storage builds

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your workstation or lab rollout, and you can extend the warranty up to 6 years to protect long lifecycle deployments built on the 90MB18E0-M0EAY0.

Technical details of 90MB18E0-M0EAY0

CPU Socket: V (LGA 1700)

Onboard Memory: No

RAID Support: Yes

CPU Manufacturer: Intel

CPU Supported Type: Core i9, Core i7, Core i5, Core i3, Celeron

Form Factor: ATX

Chipset: Intel Z690

RAM Maximum Capacity: 128GB

Max RAM Frequency : 6400MHz

RAM Slots: 4 DIMM DDR5

RAM Channels: Dual-Channel

PCIe Slots: 1 PCIe 4.0 x16, 1 PCIe 5.0 x16

M.2 Slots: 1 PCIe 3.0 x4 M.2 2280, M.2 2260, M.2 2242 M-Key, 1 PCIe 4.0 M.2 2260, M.2 2280, M.2 2242, M.2 22110 M-Key, 1 PCIe 4.0/SATA M.2 2280, M.2 2260, M.2 2242 M-Key, 1 PCIe M.2 2230 E-Key

Network Ports: 1 RJ45 2.5 Gbps

ECC Support: Non-ECC

Onboard Network: Ethernet

Onboard CPU: No

RAID Support: Yes

Onboard Graphic: No

Trusted Platform Module (TPM): Yes

BIOS: AMI UEFI

Wi-Fi Support: Wi-Fi 6E

Bluetooth integrated: 5.3

Onboard Audio Chipset: Realtek ALC4082

Embedded: No

How long is the Warranty and how you can get technical support for 90MB18E0-M0EAY0

Warranty:	36 months (part)
On site service:	yes
RMA Url:	https://www.asus.com/support/warranty-status-inquiry
Description:	In the event of an RMA, the item must be returned first. ASUS typically offers a replacement or repair service depending on the product and warranty terms. On-site service may be available for specific products such as Barbone/Full System. Carry-in.
