MBD-X11SBA-LN4F-B Supermicro Mini-ITX Single FCBGA1170 2 SO-DIMM Slots Server Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for MBD-X11SBA-LN4F-B and save cash:

Quantity	Unit price
To 9	€302.00
To 19	€288.00 €302.00 (4.64% saved)
To 49	€282.00 €302.00 (6.62% saved)
From 50	€273.00 €302.00 (9.6% saved)

Product line:

X11

See all Embedded Motherboard

See other Supermicro products

€302.00

Out of stock

Not available

Happyware Article Number:

SH9M1850-901604

Manufacturer Number:

MBD-X11SBA-LN4F-B

Brand:

Supermicro

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

MBD-X11SBA-LN4F-B

High-Density Mini-ITX Embedded Server Motherboard featuring onboard Intel SoC and remote management with the MBD-X11SBA-LN4F-B

The MBD-X11SBA-LN4F-B is a Supermicro X11 Mini-ITX embedded server motherboard engineered for low-power edge roles where deterministic performance, multiple NICs, and out-of-band control are required. Its onboard Intel Atom/Pentium-class SoC platform targets 24/7 appliance duty with a 6W TDP profile, while integrated Intel HD Graphics supports basic local console needs without consuming expansion resources.

For memory, the MBD-X11SBA-LN4F-B implements 2 DDR3 SO-DIMM slots with non-ECC support up to 8GB at up to 1600MT/s, aligning with lightweight virtualisation labs, branch services, and network functions that prioritise efficiency over large memory footprints. I/O architecture is designed for compact storage and serviceability: 2 SATA III 6Gb/s ports cover standard SSD/HDD options, complemented by Mini-PCIe with mSATA support and a SuperDOM header for embedded boot media. Expansion is provided via a PCIe Gen2 slot (x1 electrical, x8 physical) suited to specialised NICs or I/O cards rather than GPU-class acceleration.

Why Choose the MBD-X11SBA-LN4F-B?

The MBD-X11SBA-LN4F-B delivers a pragmatic density-to-performance balance for edge deployments by combining multi-port Ethernet, compact Mini-ITX integration, and IPMI-based remote operations in a single board. The platform scales cleanly across fleets of appliances and micro-nodes where consistent configuration, low heat output, and predictable I/O matter more than raw compute.

Supermicro engineering focuses on long-life embedded platforms with enterprise-grade management, controlled component selection, and firmware practices aligned to modern data centre and edge standards. With integrated BMC/IPMI and AMI UEFI, the MBD-X11SBA-LN4F-B supports remote provisioning and lifecycle operations while maintaining TPM header support for platform security designs.

Key Applications:

Firewall and UTM appliances
SD-WAN edge nodes
Branch IT infrastructure micro-servers
Industrial gateway and control-plane services
Virtualisation lab test nodes

At Happyware - Server Hardware you benefit from non-binding offers tailored to your MBD-X11SBA-LN4F-B deployment requirements and an extended warranty of up to 6 years to secure long-term edge and appliance rollouts.

Technical details of MBD-X11SBA-LN4F-B

CPU Socket:

FCBGA1170

Onboard Memory:

RAID Support:

CPU Manufacturer:

Intel

CPU Supported Type:

Pentium Atom

Form Factor:

Mini-ITX

Chipset:

System-on-Chip (SoC)

RAM Maximum Capacity:

8GB

Max RAM Frequency :

1600MHz

RAM Slots:

2 SO-DIMM DDR3

PCIe Slots:

1 PCIe 2.0 x8

Network Ports:

1 RJ45 1 Gbps 4 RJ45 1 Gbps

ECC Support:

Non-ECC

Onboard Network:

Ethernet

Suitability:

Server

Onboard CPU:

Yes

RAID Support:

Onboard Graphic:

Yes

Video Output:

1x DisplayPort 1x HDMI 1x VGA

USB Ports:

2x USB 3.0 ports 1x USB 2.0 Type-A 2x USB 2.0 ports 4x USB 2.0

Other Ports:

2x COM Port 1x Audio Port 1x SuperDOM (Disk on Module) ports

Trusted Platform Module (TPM):

Yes

BIOS:

AMI UEFI

Wi-Fi Support:

None

Onboard Audio Chipset:

Realtek ALC888S

Embedded:

Yes

GPIO Pins:

Card Reader:

How long is the Warranty and how you can get technical support for MBD-X11SBA-LN4F-B

Warranty:	12 months (part) 36 months (labor)
Advanced replacement:	yes
RMA Url:	https://www.supermicro.com/en/support/rma/
Description:	120 days Advance Cross-Ship
