MBD-X10DRH-C-B Supermicro E-ATX Dual R (LGA 2011) 16 DIMM Slots Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for MBD-X10DRH-C-B and save cash:

Quantity	Unit price
To 4	€803.57
To 9	€779.69 €803.57 (2.97% saved)
To 19	€763.79 €803.57 (4.95% saved)
From 20	€747.79 €803.57 (6.94% saved)

Product line:

X10

See all Dual CPU Motherboard

See other Supermicro products

€803.57

Out of stock

Happyware Article Number:

SH0M4507-695347

Manufacturer Number:

MBD-X10DRH-C-B

Brand:

Supermicro

Are you a reseller?

Do you have questions about this product MBD-X10DRH-C-B?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

MBD-X10DRH-C-B

High-Performance E-ATX Dual-Socket Server Motherboard featuring Intel C612 architecture with the MBD-X10DRH-C-B

The MBD-X10DRH-C-B is an enterprise E-ATX motherboard engineered for dual-socket Intel Xeon E5 v3/v4 platforms on LGA2011, enabling cost-controlled refresh and repair cycles in established data centre fleets. With the Intel C612 chipset, the MBD-X10DRH-C-B delivers a stable I/O foundation for general compute, virtualisation clusters, and storage-heavy nodes that prioritise predictable behaviour over platform churn.

For memory-intensive workloads, the MBD-X10DRH-C-B provides 16 DDR4 ECC DIMM slots in quad-channel per CPU, scaling to high-capacity configurations for dense VM consolidation and in-memory caching. Expansion is built around PCIe 3.0 with 1x x16 FHFL slot for accelerator or high-bandwidth adapter use plus 6x x8 FHFL slots for NICs, HBAs, and RAID controllers, supporting balanced lane allocation across compute and storage roles. Storage connectivity is a key architectural differentiator: 10x SATA III and 8x SAS 12Gb/s ports enable high port density and flexible attachment strategies, from boot mirrors to large direct-attached arrays, with RAID capabilities determined by the chosen controller stack.

Why Choose the MBD-X10DRH-C-B?

The MBD-X10DRH-C-B is a pragmatic foundation for extending dual-socket Xeon E5 infrastructure, combining high DIMM count, substantial PCIe 3.0 expansion, and integrated out-of-band management for scalable operations. Its density-to-performance profile supports multi-role deployments where storage growth, adapter diversity, and serviceability must coexist within a standard E-ATX footprint.

Supermicro designs platforms with an emphasis on validated server interoperability, long-life availability, and remote management alignment for modern rack environments. The board integrates IPMI 2.0 with a dedicated management LAN, UEFI BIOS, TPM support, and hardware monitoring features to improve control, auditing, and uptime discipline.

Key Applications:

Dual-socket Xeon E5 v3/v4 server repairs and refresh
Virtualisation and general-purpose compute nodes
Storage servers with high-port-count SATA/SAS attachment
Network and security appliance builds with multiple add-in cards

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your procurement and deployment requirements for the MBD-X10DRH-C-B, and can secure an extended warranty up to 6 years to reduce operational risk in long-running enterprise installations.

Technical details of MBD-X10DRH-C-B

CPU Socket:

R (LGA 2011)

Onboard Memory:

RAID Support:

Yes

CPU Manufacturer:

Intel

CPU Supported Type:

Xeon E5

Form Factor:

E-ATX

Chipset:

Intel C612

RAM Maximum Capacity:

2000GB

Max RAM Frequency :

2400MHz

RAM Slots:

16 DIMM DDR4

RAM Channels:

Quad-Channel

PCIe Slots:

1 PCIe 3.0 x16 6 PCIe 3.0 x8

Network Ports:

2 RJ45 1 Gbps

ECC Support:

ECC

Onboard Network:

Ethernet

Onboard CPU:

RAID Support:

Yes

Onboard Graphic:

Yes

Video Output:

1x VGA

USB Ports:

2x USB 3.2 Gen 1 Type-A 2x USB 2.0 Type-A

Other Ports:

2x USB 2.0/1.1 ports 1x RJ-45 (management) 2x RJ-45 (1000Base-T, Intel I350-AM2) 1x D-Sub port 1x Serial Ports 2x USB 3.2 Gen 1 ports

Trusted Platform Module (TPM):

Yes

BIOS:

AMI UEFI

Onboard Audio Chipset:

Embedded:

How long is the Warranty and how you can get technical support for MBD-X10DRH-C-B

Warranty:	12 months (part) 36 months (labor)
Advanced replacement:	yes
RMA Url:	https://www.supermicro.com/en/support/rma/
Description:	120 days Advance Cross-Ship
