MBD-A2SAV-L-B

Embedded Mini-ITX Edge Server Motherboard engineered for low-power control with the MBD-A2SAV-L-B

The MBD-A2SAV-L-B is a Supermicro embedded Mini-ITX server motherboard designed for edge compute, remote site control, and compact infrastructure services where deterministic I/O matters more than raw core count. Its onboard Intel Atom SoC with integrated Intel HD Graphics 500 and a 9W TDP supports fanless or constrained-airflow chassis designs while maintaining enterprise-grade platform stability for always-on deployments.

With a 1x DDR3L SO-DIMM memory architecture (non-ECC) up to 8GB at 1866 MT/s, the MBD-A2SAV-L-B targets lightweight services, gateways, and monitoring nodes that prioritize power budget and footprint. Storage options balance simplicity and serviceability via 2x SATA III 6Gb/s ports, SATA DOM support, and an M.2 M-Key slot (2242/2280, SATA) for solid-state boot media. A PCIe 2.0 expansion slot (x2 electrical) enables add-in NICs or specialty controllers, while dual Intel I210-IT 1GbE ports provide predictable throughput and driver maturity across common server operating environments.

Why Choose the MBD-A2SAV-L-B?

The MBD-A2SAV-L-B delivers a high density-to-performance ratio for edge and embedded racks by integrating compute, graphics, and essential I/O on a stable Mini-ITX platform. It scales through straightforward storage and PCIe expansion, supports wide operating temperatures for industrial deployments, and aligns with controlled change management by avoiding unnecessary management subsystems when out-of-band access is not required.

Supermicro designs platforms with a focus on long-lifecycle availability, conservative firmware behavior, and component interoperability suited to modern data centre and industrial standards. The MBD-A2SAV-L-B reflects this philosophy through balanced connectivity, mature Intel networking, and pragmatic power-input options for appliance and control-system integration.

Key Applications:

Edge gateways and protocol translation
Remote site monitoring and telemetry
Industrial control and serial device integration
Lightweight network services (DNS/DHCP)
Embedded appliance builds

At Happyware - Server Hardware you benefit from non-binding offers tailored to your deployment target for the MBD-A2SAV-L-B, enabling accurate BOM planning for edge and industrial rollouts, and you can extend the warranty up to 6 years to secure lifecycle coverage for long-running installations.

Technical details of MBD-A2SAV-L-B

CPU Socket:

FCBGA1296

Onboard Memory:

RAID Support:

CPU Manufacturer:

Intel

CPU Supported Type:

Atom

Form Factor:

Mini-ITX

Chipset:

System-on-Chip (SoC)

RAM Maximum Capacity:

8GB

Max RAM Frequency :

1866MHz

RAM Slots:

1 SO-DIMM DDR3L

PCIe Slots:

1 PCIe 2.0 x8

M.2 Slots:

1 SATA M.2 2280, M.2 2242 M-Key

Network Ports:

2 RJ45 1 Gbps

ECC Support:

Non-ECC

Onboard Network:

Ethernet

Suitability:

Server

Onboard CPU:

Yes

RAID Support:

Onboard Graphic:

Yes

Video Output:

1x DisplayPort 1x HDMI 1x VGA

USB Ports:

2x USB 3.0 4x USB 2.0

Other Ports:

3x COM Port 1x SATA DOM (Disk on Module)

Trusted Platform Module (TPM):

BIOS:

AMI UEFI

Wi-Fi Support:

None

Onboard Audio Chipset:

Embedded:

Yes

GPIO Pins:

Card Reader:

How long is the Warranty and how you can get technical support for MBD-A2SAV-L-B

Warranty:	12 months (part) 36 months (labor)
Advanced replacement:	yes
RMA Url:	https://www.supermicro.com/en/support/rma/
Description:	120 days Advance Cross-Ship
