Intel Xeon E-2224G 4 Cores 4 Threads 4.7GHz H4 (LGA 1151) CM8068404173806 Server CPU

*Picture may not be exactly the same as the product

Product line:

Xeon E

See all Intel Xeon E3

See other Intel products

This product is currently not priced. Request a personalized quote now.

Out of stock

Happyware Article Number:

SH6C6864-927008

Manufacturer Number:

CM8068404173806

Brand:

Intel

Are you a reseller?

Do you have questions about this product CM8068404173806?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

Intel Xeon E-2224G

Enterprise 1S LGA1151 Server CPU enabling efficient edge and SMB compute with the Intel Xeon E-2224G

The Intel Xeon E-2224G is a Coffee Lake-ER based server processor designed for 1-socket LGA1151 platforms where predictable performance, low complexity, and platform longevity are key. The 4-core design with high turbo headroom supports responsive infrastructure services, while Intel UHD Graphics P630 enables integrated console and basic media/visual acceleration without requiring a discrete GPU.

For memory, the Intel Xeon E-2224G pairs with Intel C242/C246 server chipsets to support ECC UDIMM, providing error correction for file/print, directory services, and line-of-business stacks in small footprints. Expansion is aligned to PCIe 3.0 with up to 16 CPU lanes, fitting typical edge/branch requirements such as a NIC upgrade, RAID/HBA, or a small accelerator card, while leaving storage architecture to the platform’s chipset and backplane design for SATA/SAS/NVMe mix. With VT-x, VT-d, and EPT, the Intel Xeon E-2224G is well suited to light virtualization and secure multi-role consolidation.

Why Choose the Intel Xeon E-2224G?

The Intel Xeon E-2224G delivers an effective density-to-performance profile for compact servers that must stay serviceable and reliable, balancing 71W thermal design with enterprise instruction support such as AES-NI and AVX2. As a 1S platform CPU, it scales through standardized LGA1151 ecosystems and chipset-qualified server boards, simplifying repeatable deployments across branch locations.

Intel’s server CPU engineering focuses on validated platform interoperability, stable firmware roadmaps, and features that align with modern data center operational requirements, including security technologies such as TXT and SGX where supported by the platform.

Key Applications:

SMB file and print services
Active Directory and infrastructure roles
Light virtualization on 1S hosts
Edge and branch office compute
Integrated graphics console and KVM scenarios

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your rollout plans for the Intel Xeon E-2224G, and can secure bulk order discount options when standardizing multiple edge or SMB systems on the same CPU platform.

Technical details of Intel Xeon E-2224G

L3 Cache:

8MB

Socket:

H4 (LGA 1151)

Threads:

Family:

Xeon

Code Name:

Coffee Lake-ER

Cores:

Base Clock Speed:

3.5GHz

Boost Frequency:

4.7GHz

Max Supported Memory Speed:

2666 MHz

Memory Channels:

6-Channel

TDP (Thermal Design Power):

71W

ECC:

Yes

Suitability:

Server

Intergrated Graphics (iGPU):

Intel UHD Graphics P630

Cooler:

Boxed / Tray:

Tray

Supported Chipset:

C242 C246

Hyper Threading:

64-Bit Support:

Yes

Serie:

Xeon E

Front Side Bus (FSB):

350MHz

L2 Cache:

1MB

How long is the Warranty and how you can get technical support for Intel Xeon E-2224G

Warranty:	12 months (part)
RMA Url:	https://supporttickets.intel.com/s/warrantyinfo?language=en_US
Description:	Items must be returned first before a replacement is sent. Intel does not offer on-site service as standard.
