Intel Pentium Gold G6505T 2 Cores 4 Threads H5 (LGA 1200) CM8070104291709 CPU

Power-Efficient Single-Socket Server/Workstation CPU Platform with Intel Pentium Gold G6505T for LGA1200 Deployments

The Intel Pentium Gold G6505T (SKU CM8070104291709) is a 10th Gen Comet Lake processor designed for single-socket LGA1200 systems where predictable x86 compatibility and low thermal output matter more than core count. With a 35W TDP and 2 cores / 4 threads, the Intel Pentium Gold G6505T fits entry server nodes, branch appliances, and compact workstations that need stable baseline compute and simple platform integration.

For memory architecture, the Intel Pentium Gold G6505T supports dual-channel DDR4 up to 2666 MT/s with up to 64GB addressable capacity, enabling cost-controlled configurations for directory services, lightweight virtualization, and office compute. Expansion is driven by PCIe 3.0 with up to 16 CPU lanes, aligning with straightforward NIC, HBA, or accelerator-less designs. Storage connectivity is typically platform-led via the LGA1200 chipset, allowing SATA and NVMe design flexibility while keeping the CPU focused on core execution. Integrated Intel UHD Graphics 630 supports up to 3 displays, which is valuable for edge systems and SMB workstations that require local console capability without a discrete GPU.

Why Choose the Intel Pentium Gold G6505T?

The Intel Pentium Gold G6505T provides an efficient density-to-performance profile for standardized 1S deployments where power budgeting, compact cooling, and platform consistency are key constraints. The Intel Pentium Gold G6505T also supports Intel VT-x and VT-d for controlled consolidation, plus AES-NI and platform security features to align with enterprise hardening requirements in distributed environments.

Intel engineering emphasizes long-lived platform stability, validated instruction set behavior, and ecosystem interoperability, helping IT teams deploy the Intel Pentium Gold G6505T into supported LGA1200 server and workstation designs with predictable lifecycle management and consistent firmware expectations.

Key Applications:

• Entry server infrastructure services
• Light virtualization and lab hosts
• Edge and branch gateways
• SMB workstation productivity
• Appliance-style x86 deployments

At Happyware - Server Hardware you benefit from Non-Binding Offers that fit your target platform and rollout quantities, and you can extend the warranty up to 6 years to secure longer service intervals for Intel Pentium Gold G6505T-based systems.
