R284-A94-AAL1 Gigabyte Dual Xeon 6 SoC 2U 6NR284A94DR000AAL1 Server Barebone

Product line:

Gigabyte R Series

See all Rackmount Servers 2U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Happyware Article Number:

SH8B7202-632603

Manufacturer Number:

6NR284A94DR000AAL1

Brand:

Gigabyte

Are you a reseller?

Do you have questions about this product 6NR284A94DR000AAL1?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R284-A94-AAL1 Gigabyte

High-Density 2U Dual-Socket Storage-Oriented Rack Server Barebone with PCIe Gen5 using the R284-A94-AAL1 Gigabyte

The R284-A94-AAL1 Gigabyte is a 2U dual-socket Intel Xeon 6 platform engineered for storage-first architectures that still require high core density and wide PCIe Gen5 connectivity. Built for Granite Rapids Xeon 6900 with P-cores (up to 500W TDP per CPU), it targets I/O-heavy consolidation where CPU throughput, memory bandwidth, and expansion lanes must scale together; single-CPU deployments may reduce available PCIe and memory functions.

For memory-intensive services, the R284-A94-AAL1 Gigabyte integrates 24 DDR5 ECC RDIMM/MRDIMM slots to sustain large footprints and predictable reliability for virtualisation and software-defined storage control planes. The storage topology is designed for tiering: 14 hot-swap bays (12 front, 2 rear) with hybrid backplane support, where selected bays can operate as NVMe/SAS/SATA and remaining bays support SAS/SATA via the appropriate storage controller. Additional OS and cache separation is enabled through 3 M.2 NVMe PCIe Gen5 slots. Expansion is optimised for modern fabrics and adapters with 7 PCIe 5.0 x16 slots plus dual OCP NIC 3.0 SFF PCIe 5.0 x16, complemented by out-of-band management through an AST2600 BMC with IPMI and HTML5 KVM.

Why Choose the R284-A94-AAL1 Gigabyte?

The R284-A94-AAL1 Gigabyte delivers a practical density-to-performance ratio for enterprise storage nodes by combining dual-socket compute, high DDR5 capacity, and PCIe Gen5 lane availability for HBAs, RAID/VROC, and high-speed NICs. Its hybrid bay design supports phased adoption of NVMe while retaining cost-efficient SAS/SATA tiers, enabling scalable deployment across private cloud clusters and edge aggregation racks.

Gigabyte designs the R Series around serviceability, remote lifecycle control, and compliance with modern data centre power and management expectations, enabling repeatable integration into standard 2U rack workflows with redundant power and robust platform monitoring.

Key Applications:

Software-defined storage
Hybrid NVMe and SAS/SATA tiered storage
Virtualisation and private cloud consolidation
High-I/O database and analytics
Edge storage aggregation

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your requirements for the R284-A94-AAL1 Gigabyte, supporting fast approval cycles for enterprise rollouts. For larger deployments, bulk order discounts help standardise node configurations across clusters while keeping procurement efficient.

Technical details of R284-A94-AAL1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

BR (LGA 7529)

CPU Family:

Xeon 6

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon 6900 w/ P-cores Xeon 6 SoC

Supported CPU Generation:

6th

Supported CPU Codename:

Granite Rapids

Nodes:

RAM Type:

RDIMM MRDIMM

RAM Max. Total:

6TB

RAM Slots Total:

Memory Slots:

ECC:

ECC

Bays:

2x 2.5" HotSwap SATA, SAS 4x 2.5"/3.5" HotSwap NVMe, SATA, SAS 8x 2.5"/3.5" HotSwap SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

6x PCIe 5.0 x16 (x16 mode) 1x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

1x PCIe 5.0 x16 Low-Profile 6x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps I350-AM2

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

USB Type-A LED Indicators

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

2700W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Power Supply Cooler:

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

500W

Applications:

Enterprise Applications Enterprise Server High End Enterprise Server Networking Hybrid/Private Cloud Server

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

Pre-installed Components:

None

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Certificates:

80 Plus Titanium

Chassis Intrusion:

How long is the Warranty and how you can get technical support for R284-A94-AAL1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
