R283-Z92-AAV1 Gigabyte
High-Density 2U Dual-Socket SP5 Rack Server Barebone optimized for I/O and virtualization with the R283-Z92-AAV1 Gigabyte
The R283-Z92-AAV1 Gigabyte barebone is a 2U platform built around dual-socket AMD EPYC 9005/9004 (Turin/Genoa) on SP5, enabling high core density with up to 400W TDP per CPU for consolidation-focused deployments. With 24 DDR5 ECC RDIMM slots across 12 memory channels per CPU, the architecture is designed to sustain VM-heavy memory bandwidth and predictable latency while scaling capacity up to 6TB for large private cloud footprints.
To balance compute with expansion, the R283-Z92-AAV1 Gigabyte provides 4 PCIe 5.0 x16 FHHL slots for high-throughput HBAs, RAID controllers, or accelerator-class I/O, while 16 hot-swap 2.5-inch bays support dense SATA/SAS tiers via a SATA 6Gb/s or SAS 12Gb/s backplane (SAS requires an add-in controller). For OS and hypervisor separation, 3 M.2 NVMe sockets (M-Key 22110/2280) deliver dedicated boot options, and dual OCP NIC 3.0 SFF connectors (PCIe 5.0 x16, NCSI capable) complement the integrated 2 x 1GbE for flexible fabric design.
Why Choose the R283-Z92-AAV1 Gigabyte?
The R283-Z92-AAV1 Gigabyte targets enterprises that need a strong density-to-performance ratio in a standardized 2U footprint, combining PCIe 5.0 expansion with storage-rich front bays for scalable virtualization or appliance-style network services. Redundant 1600W 80 PLUS Titanium hot-swap PSUs, ECC memory support, and remote management via the ASPEED AST2600 BMC help maintain uptime and operational consistency as clusters grow.
Gigabyte engineering emphasizes serviceability and data center alignment, integrating IPMI-based out-of-band control, OCP-ready networking, and modular RAID/HBA options to fit modern rack, power, and lifecycle management practices. The R283-Z92-AAV1 Gigabyte also supports a TPM header for environments requiring measured-boot readiness.
Key Applications:
- VMware and Hyper-V virtualization consolidation
- Private cloud compute nodes
- Database hosting with dense 2.5-inch tiers
- Storage-centric compute with SAS/SATA pools
- Network services and security appliances
At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your R283-Z92-AAV1 Gigabyte rollout requirements, helping you standardize configurations across projects, and you can extend the warranty up to 6 years to secure long-term platform availability in enterprise operations.
Technical details of R283-Z92-AAV1 Gigabyte
How long is the Warranty and how you can get technical support for R283-Z92-AAV1 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
