E283-Z91-AAV1 Gigabyte Dual EPYC 9004 2U 6NE283Z91DR000ACV1 Server Barebone

Get extra volume discount for 6NE283Z91DR000ACV1 and save cash:

Quantity	Unit price
	€3,550.00
To 4	€3,480.00 €3,550.00 (1.97% saved)
To 9	€3,410.00 €3,550.00 (3.94% saved)
From 10	€3,340.00 €3,550.00 (5.92% saved)

Product version:

Rev-3.x

Product line:

Gigabyte E Series

See all Rackmount Servers 2U

See other Gigabyte products

€3,550.00

Out of stock

Not available

Happyware Article Number:

SH0B4487-548535

Manufacturer Number:

6NE283Z91DR000ACV1

Brand:

Gigabyte

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

E283-Z91-AAV1 Gigabyte

High-Density 2U Dual-Socket SP5 Rack Server Barebone engineered for scalable HPC and virtualisation with the E283-Z91-AAV1 Gigabyte

The E283-Z91-AAV1 Gigabyte barebone is a 2U, 1-node platform built around dual SP5 (LGA6096) sockets to support AMD EPYC 9005/9004 processors, enabling high core density and sustained throughput for consolidated enterprise services. Its DDR5 ECC RDIMM design with 24 DIMM slots and a 12-channel per CPU memory architecture is optimised for bandwidth-driven virtualisation and analytics, reducing contention under multi-VM and multi-tenant workloads.

To keep I/O aligned with modern CPU capability, the E283-Z91-AAV1 Gigabyte integrates 6 PCIe 5.0 x16 FHHL slots for accelerator, storage, or high-speed networking expansion, complemented by 2 OCP NIC 3.0 SFF PCIe 5.0 x16 slots for scalable NIC selection. Storage is architected for serviceability and mixed profiles via 4 x 2.5" hot-swap SATA/SAS bays (SAS-4 capable with the appropriate HBA) and dual M.2 NVMe sockets for boot or cache, supporting separation of OS and data paths. Remote operations are streamlined through an ASPEED AST2600 BMC with IPMI and HTML5 KVM.

Why Choose the E283-Z91-AAV1 Gigabyte?

The E283-Z91-AAV1 Gigabyte delivers a balanced density-to-performance profile by pairing dual-socket compute with high memory bandwidth and PCIe 5.0 expansion, allowing one chassis design to scale from edge consolidation to core virtualisation. Redundant 1600W Titanium-rated hot-swap power and out-of-band management support predictable availability and repeatable deployment across fleets.

Gigabyte server engineering emphasises platform longevity, validated component integration, and adherence to data centre operational standards, enabling consistent thermals, service access, and manageability for enterprise rack environments.

Key Applications:

Virtualisation and private cloud consolidation
Edge and branch infrastructure hosting
Network services and security appliances
HPC and technical computing clusters
Software-defined storage and NVMe caching tiers

At Happyware - Server Hardware you benefit from non-binding offers tailored to the exact E283-Z91-AAV1 Gigabyte configuration and an extended warranty of up to 6 years to secure long-term platform operation in production environments.

Technical details of E283-Z91-AAV1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

SP5 (LGA 6096)

CPU Family:

EPYC

Supported CPU Manufacturer:

AMD

Supported CPU Type:

EPYC 9004 EPYC 9005

Supported CPU Generation:

4th 5th

Supported CPU Codename:

Genoa Turin

Nodes:

RAM Type:

RDIMM

RAM Max. Total:

6TB

RAM Slots Total:

ECC Support:

ECC

Bays:

4x 2.5" HotSwap SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

6x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

6x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps Intel I350-AM2

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

NMI button System status LED Storage Activity LED LAN Activity LED Power button with LED System Reset button USB Unit Identification (UID) button

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

1600W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

400W

Applications:

Cloud Computing Edge Computing Networking Hybrid/Private Cloud Server Enterprise

Onboard CPU:

Onboard Graphic:

Aspeed AST2600

Graphics Manufacturer:

ASpeed

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Chassis Intrusion:

OS:

Citrix Hypervisor (formerly XenServer) Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server 2019 Windows Server 2022 Windows Server 2025

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C

How long is the Warranty and how you can get technical support for E283-Z91-AAV1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
