R283-Z94-AAV2 Gigabyte Dual EPYC 9005 2U 6NR283Z94DR000ACV2 Server Barebone

Get extra volume discount for 6NR283Z94DR000ACV2 and save cash:

Quantity	Unit price
	€3,490.00
To 4	€3,430.00 €3,490.00 (1.72% saved)
To 9	€3,360.00 €3,490.00 (3.72% saved)
From 10	€3,290.00 €3,490.00 (5.73% saved)

Product version:

Rev-3.x

Product line:

Gigabyte R Series

See all Rackmount Servers 2U

See other Gigabyte products

€3,490.00

Out of stock

Not available

Happyware Article Number:

SH0B1326-252707

Manufacturer Number:

6NR283Z94DR000ACV2

Brand:

Gigabyte

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R283-Z94-AAV2 Gigabyte

High-Density 2U Dual-Socket SP5 Rack Server Barebone with PCIe Gen5 Expansion: R283-Z94-AAV2 Gigabyte

The R283-Z94-AAV2 Gigabyte barebone is a 2U, 1-node platform engineered for dual-socket AMD EPYC 9005/9004 (SP5) deployments where core density and I/O throughput must scale together. With support for high-TDP processors and a balanced board layout, it targets virtualization hosts, scale-out compute clusters, and data analytics nodes that need predictable performance under sustained load.

Memory architecture is optimized around 24 DDR5 ECC RDIMM slots, delivering 12-channel bandwidth per CPU and capacity headroom up to 6TB for memory-intensive databases and distributed processing. PCIe Gen5 is exposed through 4 x PCIe 5.0 x16 slots and 2 x OCP NIC 3.0 SFF bays (PCIe 5.0 x16 with NCSI), enabling flexible NIC selection and accelerator-ready expansion while maintaining serviceability. Storage is split for operational efficiency: 12 front hot-swap bays with 4 bays supporting NVMe (PCIe Gen5 x4) or SATA/SAS plus 8 SATA/SAS bays, complemented by 2 rear hot-swap 2.5" bays and dedicated OS provisioning via 3 x M.2 NVMe slots.

Why Choose the R283-Z94-AAV2 Gigabyte?

The R283-Z94-AAV2 Gigabyte delivers a strong density-to-performance profile by pairing dual SP5 compute with PCIe Gen5 connectivity, allowing IT teams to standardize a single 2U node design across cloud, analytics, and edge-core roles. Redundant 1600W 80 PLUS Titanium power, enterprise RAID/HBA options, and out-of-band management support reliable scaling in rack-level deployments.

Gigabyte designs this platform around data center operability: hot-swap power and drive access, a dedicated management network via ASPEED AST2600 BMC with IPMI/HTML5 KVM, and component choices aligned to modern power-efficiency and remote-administration standards.

Key Applications:

Hybrid and private cloud virtualization
Scale-out compute clusters
Memory-intensive databases
Distributed data analytics
High-I/O networking and edge core

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your R283-Z94-AAV2 Gigabyte configuration requirements and an extended warranty of up to 6 years to protect long-life infrastructure rollouts.

Technical details of R283-Z94-AAV2 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

SP5 (LGA 6096)

CPU Family:

EPYC

Supported CPU Manufacturer:

AMD

Supported CPU Type:

EPYC 9004 EPYC 9005

Supported CPU Generation:

4th 5th

Supported CPU Codename:

Genoa Turin

Nodes:

RAM Type:

RDIMM

RAM Max. Total:

6TB

RAM Slots Total:

ECC Support:

ECC

Bays:

2x 2.5" HotSwap SATA, SAS 4x 2.5"/3.5" HotSwap NVMe, SATA, SAS 8x 2.5"/3.5" HotSwap SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

4x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

4x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps Intel I350-AM2

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

NMI button System status LED Storage Activity LED LAN Activity LED Power button with LED System Reset button USB UID button with LED

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

1600W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

400W

Applications:

Networking Hybrid/Private Cloud Server Enterprise

Onboard CPU:

Onboard Graphic:

Aspeed AST2600

Graphics Manufacturer:

ASpeed

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Certificates:

80 Plus Titanium

Chassis Intrusion:

OS:

Citrix Hypervisor (formerly XenServer) Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server 2019 Windows Server 2022 Windows Server 2025

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C

How long is the Warranty and how you can get technical support for R283-Z94-AAV2 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
