B7119F77V14HR-2T55-N Tyan FA77B7119 Dual Xeon Scalable 2nd Gen 4U Server Barebone

See all Server Systems

See other Tyan products

This product is currently not priced. Request a personalized quote now.

In stock

Happyware Article Number:

SE7B2775-290993

Manufacturer Number:

B7119F77V14HR-2T55-N

Brand:

Tyan

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

B7119F77V14HR-2T55-N

Enterprise Tyan Platform Server Hardware for configurable data centre builds with the B7119F77V14HR-2T55-N

The B7119F77V14HR-2T55-N is a Tyan enterprise platform identifier intended for server hardware deployments where the exact CPU generation, GPU enablement, and chassis form factor are defined by the final configuration. For infrastructure architects, the B7119F77V14HR-2T55-N should be treated as a procurement anchor for a validated Tyan platform, while core design decisions such as socket family, accelerator topology, and rack density must be confirmed against the final bill of materials.

Because the B7119F77V14HR-2T55-N is provided without explicit CPU, memory, PCIe generation, storage backplane, or network controller details, system engineering must validate architectural fit before committing it to production. Key acceptance points typically include memory architecture (ECC support, channel population strategy), expansion capabilities (PCIe lane availability for NICs, HBAs, and GPUs), storage layout (NVMe/SAS/SATA mix and hot-swap design), and management features (BMC telemetry and remote lifecycle control). This verification ensures the platform aligns with general-purpose compute, virtualization, or storage-oriented roles without introducing I/O bottlenecks or serviceability constraints.

Why Choose the B7119F77V14HR-2T55-N?

The B7119F77V14HR-2T55-N supports standardized enterprise deployment workflows by locking in a Tyan platform reference while allowing configuration to match required performance density, redundancy, and expansion headroom. Selecting the B7119F77V14HR-2T55-N is most effective when paired with a qualification process that maps workload profiles to CPU core count, memory bandwidth, PCIe topology, and storage tiers, ensuring predictable scaling and operational consistency across racks.

Tyan focuses on server platforms engineered for data centre reliability, serviceability, and long-term lifecycle alignment. For the B7119F77V14HR-2T55-N, this typically translates into controlled platform validation, enterprise integration expectations, and compatibility with modern management and infrastructure standards once the final configuration is confirmed.

Key Applications:

General-purpose compute nodes
Virtualization clusters
Infrastructure services consolidation
Private cloud building blocks

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your B7119F77V14HR-2T55-N deployment requirements, enabling faster approval cycles for standardized rollouts. For multi-node projects, bulk order discount options support cost-efficient scaling while maintaining consistent platform sourcing.

Technical details of B7119F77V14HR-2T55-N

Type:

Rack

Suitability:

Server

CPU Socket:

P (LGA 3647)

CPU Family:

Xeon

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon Scalable 1st Gen Xeon Scalable 2nd Gen

Supported CPU Generation:

1st 2nd

Supported CPU Codename:

Cascade Lake Skylake

Nodes:

RAM Type:

RDIMM LRDIMM

RAM Max. Total:

3TB

RAM Slots Total:

Bays:

14x 2.5" HotSwap SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

10x PCIe 3.0 x16 (x16 mode) 1x PCIe 3.0 x16 (x16 mode)

Expansion Slots:

10x PCIe 3.0 x16 Full-Height Full-Length (Standard) 1x PCIe 3.0 x16 Full-Height Full-Length (Standard)

Onboard Network LAN:

2x RJ45 10 Gbps X550-BT2

Onboard Network LAN Speed:

10 Gbps

Front I/O Ports:

NMI button System Reset button Power status LED UID button with LED

Other Ports:

1x COM Port

IPMI / BMC integrated:

Yes

Chipset:

Intel C621

Power Supply Wattage:

4800W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Platinum

Quantity of Cooler:

TDP (Thermal Design Power):

205W

Applications:

GPU Server Machine Learning (ML)

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

OS:

Microsoft Windows Server 2012 Enterprise R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2016 Microsoft Windows Server 2019 Standard

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 70°C

How long is the Warranty and how you can get technical support for B7119F77V14HR-2T55-N

Warranty:	36 months (part)
Advanced replacement:	yes
RMA Url:	https://www.tyan.com/EN/standard_rma/
Description:	Advanced Shippment is an Option. No guaranteed delivery times. No on-site service offered as standard.
