SYS-E100-13AD-C Supermicro IoT SuperServer Single Celeron 7305E 1U Embedded/IoT/Server Barebone
Get extra volume discount for SYS-E100-13AD-C and save cash:
| Quantity | Unit price |
|---|---|
| To 9 |
€614.33
|
| To 19 |
€583.89
€614.33
(4.95% saved)
|
| To 49 |
€571.69
€614.33
(6.94% saved)
|
| From 50 |
€553.39
€614.33
(9.92% saved)
|
Do you have a major deal consisting of various components? Then you're at the right place!
We offer you the best prices for your purchase:
- - If you already have an account with us, please log in. If you don't have an account, you can apply for one here.
- - simply collect your required items in the desired quantity in CART, and click the 'GET QUOTATION' button. and you're done!
- - You will receive your offer within the next 24 hours on working days.
IoT SuperServer
€614.33
Not available
Do you have questions about this product SYS-E100-13AD-C?
SYS-E100-13AD-C
High-Density 1U Fanless Edge Appliance optimised for IoT gateways with the SYS-E100-13AD-C
The SYS-E100-13AD-C is a 1U fanless embedded rack appliance designed for space-constrained edge deployments that require deterministic connectivity and low operational overhead. It is built around an Intel 12th Gen Alder Lake-U SoC platform (Intel Celeron 7305E, soldered) with integrated graphics, balancing multi-threaded control-plane tasks and local visualization without adding discrete accelerators.
For memory, the SYS-E100-13AD-C implements a dual DDR5 SO-DIMM architecture supporting up to 64GB non-ECC UDIMM, enabling larger in-memory caches for telemetry, protocol translation, and containerized microservices. Storage is NVMe-centric with an M.2 M-key PCIe 4.0 x4 slot for high-IOPS local persistence, complemented by additional M.2 expansion paths for USB-attached modules where required. With no PCIe add-in slots, the platform’s expansion model is intentionally simplified to M.2 to improve mechanical reliability and reduce service complexity, while dual 2.5GbE (Intel I225-IT) provides predictable edge-to-core uplink bandwidth.
Why Choose the SYS-E100-13AD-C?
The SYS-E100-13AD-C delivers a practical density-to-performance profile for distributed edge fleets: fanless 1U packaging for harsh or acoustically sensitive sites, consistent network throughput via 2.5GbE, and a storage design centered on PCIe 4.0 NVMe for fast local buffering. The SYS-E100-13AD-C also aligns well with standardized remote operations through UEFI-based lifecycle control, TPM 2.0 for platform integrity, and streamlined M.2-only serviceability that scales across multi-site rollouts.
Supermicro engineering emphasizes platform stability, validated component interoperability, and long-life embedded design practices that fit modern data centre and edge standards, including secure boot foundations, robust out-of-band health monitoring via SuperDoctor 5, and predictable I/O mapping for industrial integration.
Key Applications:
- Industrial IoT edge gateway
- Smart building controller
- Retail POS and kiosk endpoint
- Healthcare workstation gateway
- Surveillance aggregation and forwarding
At Happyware - Server Hardware you benefit from non-binding offers tailored to your SYS-E100-13AD-C deployment plan and an extended warranty of up to 6 years to secure long-running edge installations with predictable lifecycle coverage.
Technical details of SYS-E100-13AD-C
How long is the Warranty and how you can get technical support for SYS-E100-13AD-C
| Warranty: | 12 months (part) 12 months (labor) |
|---|---|
| Advanced replacement: | yes |
| RMA Url: | https://www.supermicro.com/en/support/rma/ |
| Description: | Cross-Shipment only in specific Time Frames. RMA-Number Required, No guaranteed delivery times. On-site service is not standard. |
| Support Portal: | https://support.happyware.com |
|---|
