SYS-522GA-NRT
High-Performance 5U GPU Rackmount Server featuring dual-root PCIe Gen5 scaling with the SYS-522GA-NRT
The SYS-522GA-NRT is a 5U Supermicro GPU server engineered around dual Intel Xeon 6 6900-series (Granite Rapids, LGA7529) processors to sustain high core density and accelerator-heavy throughput in a single chassis. This platform couples high-TDP CPU capability with a balanced memory subsystem, providing 24 DDR5 ECC DIMM slots supporting RDIMM or MRDIMM configurations for large in-memory datasets, model parameters, and simulation state.
To minimize contention between CPU, GPU, and storage traffic, the SYS-522GA-NRT implements a dual-root PCIe Gen5 topology with a switched CPU-to-GPU fabric and 13 full-height, full-length PCIe Gen5 x16 slots for GPUs or other accelerators. For data staging and checkpoint performance, the SYS-522GA-NRT integrates 24 hot-swap 2.5-inch U.2 NVMe bays on PCIe Gen5, complemented by dual M.2 NVMe boot options. Integrated 10GbE and IPMI/BMC management simplify integration into existing racks while enabling remote provisioning and lifecycle operations.
Why Choose the SYS-522GA-NRT?
The SYS-522GA-NRT is designed for enterprises that require predictable GPU scaling without sacrificing serviceability or rack efficiency. Its 5U footprint prioritizes airflow and power delivery for dense accelerator configurations, while the dual-root PCIe Gen5 architecture improves device locality and aggregate bandwidth for multi-GPU training, inference at scale, and HPC pipelines. With redundant, hot-swap power and tool-aware maintenance design, the SYS-522GA-NRT supports reliable deployment in production clusters and can be replicated as a consistent building block across pods.
Supermicro focuses on modular system engineering with data centre-aligned manageability, validated platform integration, and long-run component availability. This approach supports standardized build-outs, controlled change management, and operational consistency across AI and HPC fleets.
Key Applications:
- AI training clusters
- AI inference services
- HPC simulation and modelling
- VDI and visual computing
- Rendering and content pipelines
At Happyware - Server Hardware you benefit from non-binding offers tailored to your SYS-522GA-NRT deployment plan and the option to extend the warranty up to 6 years to align hardware coverage with enterprise refresh cycles.
Technical details of SYS-522GA-NRT
How long is the Warranty and how you can get technical support for SYS-522GA-NRT
| Warranty: | 12 months (part) 12 months (labor) |
|---|---|
| Advanced replacement: | yes |
| RMA Url: | https://www.supermicro.com/en/support/rma/ |
| Description: | Cross-Shipment only in specific Time Frames. RMA-Number Required, No guaranteed delivery times. On-site service is not standard. |
| Support Portal: | https://support.happyware.com |
|---|
