SYS-521R-T Supermicro SuperWorkstation Single Xeon E-2400 Server Barebone

Get extra volume discount for SYS-521R-T and save cash:

Quantity	Unit price
To 4	€717.90
To 9	€696.54 €717.90 (2.98% saved)
To 19	€682.34 €717.90 (4.95% saved)
From 20	€668.04 €717.90 (6.95% saved)

Product line:

SuperWorkstation

See all Server Systems

See other Supermicro products

€717.90

In stock

Happyware Article Number:

SH1B7265-240730

Manufacturer Number:

SYS-521R-T

Brand:

Supermicro

Are you a reseller?

Do you have questions about this product SYS-521R-T?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

SYS-521R-T

High-Density Mini-Tower Edge Server Barebone with Intel LGA1700 Platform in the SYS-521R-T

The SYS-521R-T is a single-node mini-tower server barebone engineered for branch and SMB infrastructure where Intel Xeon E-2400 or Pentium LGA1700 compute, ECC memory integrity, and serviceable storage must fit into a compact chassis. With up to 8 cores and 16 threads at up to 80W TDP, the platform targets directory services, file/print consolidation, and light virtualisation without the operational overhead of larger rack deployments.

Memory is delivered through 2 DDR5 ECC UDIMM slots (up to 64GB), prioritising predictable latency and error correction for always-on services. The SYS-521R-T provides a balanced I/O design with a PCIe 5.0 x16 half-height/half-length slot for high-throughput NICs, HBAs, or RAID controllers, complemented by 4 hot-swap 3.5in bays for SATA HDD/SSD and an internal M.2 2280 NVMe (M-Key) for OS or cache tiers. Storage flexibility is controller-dependent, enabling SATA by default and optional SAS/NVMe via add-in components to align the SYS-521R-T with backup staging or NAS-adjacent roles.

Why Choose the SYS-521R-T?

The SYS-521R-T delivers an efficient density-to-performance ratio for distributed sites by combining modern DDR5 ECC and PCIe 5.0 expansion with hot-swap serviceability in a tower footprint. Dual 1GbE plus a dedicated management port support clean separation of data and OOB access, while IPMI remote operations reduce hands-on maintenance and accelerate rollout of standardised edge nodes.

Supermicro designs platforms with a focus on enterprise operability, emphasizing validated thermals, consistent component quality, and lifecycle stability aligned to modern data centre practices. Integrated security features such as TPM 2.0 and Silicon Root of Trust (NIST 800-193) reinforce platform integrity for unattended deployments.

Key Applications:

Edge/branch office AD/DNS and file/print
Light virtualisation for SMB services
Backup and recovery disk-to-disk staging
Line-of-business applications
NAS-adjacent storage with optional HBA/RAID

At Happyware - Server Hardware you benefit from 24/7 Customer Service to support configuration and deployment planning for the SYS-521R-T, and you can secure an Extended Warranty up to 6 years to protect long-lived branch infrastructure investments.

Technical details of SYS-521R-T

Type:

Mini Tower

Suitability:

Server

CPU Socket:

V (LGA 1700)

CPU Family:

Pentium Xeon

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon E-2400 Pentium

Supported CPU Generation:

12th

Supported CPU Codename:

Alder Lake Raptor Lake

Nodes:

RAM Type:

UDIMM

RAM Max. Total:

64GB

RAM Slots Total:

ECC Support:

ECC

Bays:

4x 3.5" HotSwap NVMe, SATA, SAS

Hot-Swap:

Yes

RAID Support:

PCIe:

1x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

1x PCIe 5.0 x16 Half Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps Intel I210 1x RJ45 1 Gbps Realtek RTL8211F

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

LED Indicators Storage Activity LED LAN Activity LED Power On/Off button System Reset button Power status LED USB Fan Fail/System Over Heat LED

Other Ports:

1x COM Port

IPMI / BMC integrated:

Yes

Chipset:

Intel C262

Power Supply Wattage:

350W

Redundant Power Supply:

Number of Power Supplies:

80 Plus Certificate:

80 Plus Gold

Quantity of Cooler:

Performance Class:

Low-End

TDP (Thermal Design Power):

80W

Applications:

General Purpose Computing Small Business Entry-Level Micro-Server

Onboard CPU:

Onboard Graphic:

Aspeed AST2600

Graphics Manufacturer:

ASpeed

Pre-installed Software:

Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New! Supermicro SuperDoctor® 5 (SD5)

Certificates:

80 Plus Gold

Chassis Intrusion:

OS:

CentOS Oracle Linux Red Hat Enterprise Linux Rocky Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 90°C

Non-operating Relative Humidity:

5°C to 95°C

How long is the Warranty and how you can get technical support for SYS-521R-T

Warranty:	12 months (part) 12 months (labor)
Advanced replacement:	yes
RMA Url:	https://www.supermicro.com/en/support/rma/
Description:	Cross-Shipment only in specific Time Frames. RMA-Number Required, No guaranteed delivery times. On-site service is not standard.
