SYS-222HE-TN
High-Performance 2U GPU-Capable Rack Server Barebone with dual-socket Intel Xeon 6 and PCIe Gen5 in the SYS-222HE-TN
The SYS-222HE-TN is a 2U rack barebone engineered for dual-socket Intel Xeon 6 platforms (Granite Rapids/Sierra Forest, Xeon 6500/6700 series) and PCIe Gen5 acceleration, aligning compute density with predictable serviceability for enterprise clusters. With up to 330W CPUs, the architecture targets balanced throughput for virtualized environments, AI inference nodes, and scale-out infrastructure where core count, memory bandwidth, and I/O concurrency must scale together.
SYS-222HE-TN implements a 16-channel DDR5 ECC RDIMM memory design across 32 DIMM slots, enabling high-capacity configurations up to 8TB (2DPC) and supporting memory-bound consolidation. Expansion is centered on PCIe Gen5 with GPU-capable slot options for double-width accelerators or high slot-count NIC/HBA layouts, complemented by 2 AIOM (OCP 3.0 compatible) PCIe Gen5 x16 interfaces for adaptable networking. Storage is optimized for software-defined designs: 6 front 2.5in hot-swap bays for mixed NVMe/SAS/SATA with optional expansion, plus dual M.2 NVMe PCIe Gen5 x2 boot modules; NVMe RAID via Intel VROC enables controlled fault domains.
Why Choose the SYS-222HE-TN?
The SYS-222HE-TN delivers a strong density-to-performance ratio by combining Xeon 6 compute, DDR5 bandwidth, and PCIe Gen5 lanes in a serviceable 2U footprint, reducing platform sprawl in private cloud and GPU-assisted inference tiers. SYS-222HE-TN also supports up to 4 CXL 2.0 devices and integrates redundant 1+1 Titanium power for predictable scaling under sustained load.
Supermicro designs the SYS-222HE-TN with data center standards in mind, emphasizing validated thermals, modular I/O via AIOM, and secure lifecycle controls such as TPM 2.0, Silicon Root of Trust, Secure Boot, and signed firmware through IPMI/BMC management.
Key Applications:
- Virtualization and private cloud clusters
- Hybrid cloud edge/core infrastructure
- AI inference and GPU compute
- Software-defined storage with mixed media
- 5G core and edge platforms
At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your SYS-222HE-TN deployment and an extended warranty up to 6 years to secure long-term operation across enterprise refresh cycles.
Technical details of SYS-222HE-TN
How long is the Warranty and how you can get technical support for SYS-222HE-TN
| Warranty: | 12 months (part) 12 months (labor) |
|---|---|
| Advanced replacement: | yes |
| RMA Url: | https://www.supermicro.com/en/support/rma/ |
| Description: | Cross-Shipment only in specific Time Frames. RMA-Number Required, No guaranteed delivery times. On-site service is not standard. |
| Support Portal: | https://support.happyware.com |
|---|
