SYS-110D-20C-FRAN8TP
High-Density 1U Edge and Network Appliance Platform with the SYS-110D-20C-FRAN8TP
The SYS-110D-20C-FRAN8TP is a 1U rack server engineered for high-I/O edge and network deployments, combining an Intel Xeon D-2700 SoC platform with balanced compute and packet-processing resources. Up to 20 cores and 40 threads enable consolidation of network services, virtualized edge functions, and security workloads while keeping latency predictable in space- and power-constrained racks.
For memory integrity and deterministic behavior, the SYS-110D-20C-FRAN8TP uses DDR4 ECC Registered memory across 4 DIMM slots, scaling to 512GB for multi-tenant VNFs, inspection engines, and service chaining. PCIe 4.0 expansion is centered on a full-height, full-length x16 slot to support a double-width accelerator such as an NVIDIA L4, enabling inline AI inference, telemetry analytics, or encrypted traffic processing without saturating the I/O fabric. Storage is optimized for edge resiliency with 2 internal 2.5" SATA bays and an M.2 (NVMe/SATA) option for fast OS and logging tiers, aligned to appliance-style serviceability rather than RAID dependency.
Why Choose the SYS-110D-20C-FRAN8TP?
The SYS-110D-20C-FRAN8TP delivers a dense performance-to-I/O profile by pairing a Xeon D SoC with extensive multi-speed networking, making it well suited for distributed sites that need throughput, segmentation, and remote operations at 1U. With redundant hot-swap power, out-of-band management, and platform security controls, it supports scalable rollouts and consistent lifecycle management across edge footprints.
Supermicro focuses on modular server engineering that aligns with modern data center and edge standards, emphasizing validated component interoperability, robust remote management, and security features such as Silicon Root of Trust and TPM 2.0 support to protect firmware and configuration integrity.
Key Applications:
- Network security appliance (NGFW/UTM)
- High-throughput routing and edge aggregation
- Virtualized edge services (VNFs)
- IoT edge compute and gateway consolidation
- AI inference at the edge with PCIe 4.0 accelerators
At Happyware - Server Hardware you benefit from non-binding offers tailored to SYS-110D-20C-FRAN8TP rollout requirements and an extended warranty of up to 6 years to support long service lifecycles in distributed edge deployments.
Technical details of SYS-110D-20C-FRAN8TP
How long is the Warranty and how you can get technical support for SYS-110D-20C-FRAN8TP
| Warranty: | 12 months (part) 12 months (labor) |
|---|---|
| Advanced replacement: | yes |
| RMA Url: | https://www.supermicro.com/en/support/rma/ |
| Description: | Cross-Shipment only in specific Time Frames. RMA-Number Required, No guaranteed delivery times. On-site service is not standard. |
| Support Portal: | https://support.happyware.com |
|---|
