MBD-X12STN-E Supermicro 3.5" SBC Single FCBGA1449 2 SO-DIMM Slots Server Mainboard

*Picture may not be exactly the same as the product

Get extra volume discount for MBD-X12STN-E and save cash:

Quantity	Unit price
To 4	€774.44
To 9	€751.30 €774.44 (2.99% saved)
To 19	€735.80 €774.44 (4.99% saved)
From 20	€720.30 €774.44 (6.99% saved)

Product line:

X13

See all Embedded Motherboard

See other Supermicro products

€774.44

In stock

Happyware Article Number:

SH6M6676-619439

Manufacturer Number:

MBD-X12STN-E

Brand:

Supermicro

Are you a reseller?

Do you have questions about this product MBD-X12STN-E?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

MBD-X12STN-E

High-Performance 3.5" Embedded SBC motherboard for industrial edge compute with the MBD-X12STN-E

The MBD-X12STN-E integrates an Intel SoC platform with onboard CPU in a 3.5" SBC form factor to deliver deterministic edge compute where space, power, and thermal headroom are constrained. Designed for industrial deployments, it pairs a 28W class CPU with Intel Iris Xe graphics to support local analytics, HMI rendering, and multi-display signage without discrete GPU complexity.

With the MBD-X12STN-E, memory is optimized for compact systems via 2 DDR4 SO-DIMM slots up to 64GB at 3200 MT/s, enabling responsive protocol translation and lightweight services. PCIe-based storage is prioritized through an M-Key M.2 slot supporting PCIe 4.0 x4 NVMe for fast local data capture, complemented by a B-Key M.2 for flexible SATA/USB/PCIe integration and a dedicated SATA III port for legacy media. Expansion is aligned to embedded I/O needs with an M.2 E-Key for wireless or specialized modules, while dual 2.5GbE Intel I225-IT networking adds TSN-capable, industrial-grade connectivity for segmented control networks.

Why Choose the MBD-X12STN-E?

The MBD-X12STN-E is engineered for high I/O density per watt in ruggedized edge nodes, combining flexible M.2 expansion, multi-display outputs, and dual 2.5GbE into a compact footprint. Its industrial temperature range and DC input support help standardize deployments across factory floors, kiosks, and vehicles while maintaining predictable platform behavior through UEFI BIOS and TPM-ready security integration.

Supermicro designs embedded platforms with a focus on long-life supply planning, validated firmware stacks, and enterprise-aligned component selection. The MBD-X12STN-E reflects this approach by balancing modern PCIe storage paths, industrial networking, and serviceable I/O topology to match current data centre and edge operational standards.

Key Applications:

Industrial controllers and factory automation
IoT gateways and protocol translation
Embedded edge servers for local services
Digital signage and multi-display HMI
Local analytics at remote sites

At Happyware - Server Hardware you benefit from 24/7 Customer Service to support integration timelines and deployment questions for the MBD-X12STN-E, plus Extended Warranty options up to 6 years to protect long-life industrial installations.

Technical details of MBD-X12STN-E

CPU Socket:

FCBGA1449

Onboard Memory:

RAID Support:

CPU Manufacturer:

Intel

CPU Supported Type:

Core i5

Form Factor:

3.5" SBC

Chipset:

System-on-Chip (SoC)

RAM Maximum Capacity:

64GB

Max RAM Frequency :

3200MHz

RAM Slots:

2 SO-DIMM DDR4

Storage Ports:

1 SATA III (6Gb/s)

M.2 Slots:

1 CNVi/PCIe 3.0 x1/USB 2.0 M.2 2230 E-Key 1 PCIe 3.0 x1/USB 3.0/USB 2.0/SATA M.2 2242, M.2 2280, M.2 3042 B-Key 1 PCIe 4.0 x4/NVME M.2 2242, M.2 2280 M-Key

Network Ports:

1 RJ45 2.5 Gbps

Onboard Network:

Ethernet

Suitability:

Server

Onboard CPU:

Yes

RAID Support:

Onboard Graphic:

Yes

Video Output:

x1 LVDS 0 x2 HDMI 0 x1 DisplayPort 0

USB Ports:

x8 USB 0 x4 USB 3.1 Gen 2 0

Trusted Platform Module (TPM):

Yes

BIOS:

AMI UEFI

Wi-Fi Support:

None

Embedded:

Yes

Card Reader:

How long is the Warranty and how you can get technical support for MBD-X12STN-E

Warranty:	12 months (part) 36 months (labor)
Advanced replacement:	yes
RMA Url:	https://www.supermicro.com/en/support/rma/
Description:	120 days Advance Cross-Ship
