MBD-X11SCV-Q Supermicro Mini-ITX Single H4 (LGA 1151) 2 SO-DIMM Slots Server Mainboard

*Picture may not be exactly the same as the product

Product line:

X11

See all Embedded Motherboard

See other Supermicro products

This product is currently not priced. Request a personalized quote now.

Out of stock

Not available

Happyware Article Number:

SH2M3070-702298

Manufacturer Number:

MBD-X11SCV-Q

Brand:

Supermicro

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

MBD-X11SCV-Q

High-Density Mini-ITX Server/Embedded Motherboard featuring Intel LGA1151 edge compute design with the MBD-X11SCV-Q

MBD-X11SCV-Q is a compact Mini-ITX platform based on the Intel Q370 chipset, built for x86 edge and embedded nodes that need predictable performance within constrained chassis and power envelopes. It supports 1x LGA1151 processor across Intel Core, Pentium, and Celeron families up to 65W, enabling right-sized compute for branch services, kiosks, and industrial control without the overhead of multi-socket server platforms.

For memory, MBD-X11SCV-Q uses 2x DDR4 SO-DIMM channels up to 64GB at 2666 MT/s, aligning with appliance-class footprints while maintaining sufficient bandwidth for mixed I/O and service workloads. PCIe 3.0 expansion is delivered through a full-length x16 slot (electrical x16) for accelerator, NIC, or storage HBA integration, and the storage topology balances local capacity and low latency via 5x SATA III ports plus an M.2 (M-Key) PCIe 3.0 x4 NVMe path. Dual 1GbE onboard networking and platform features such as RAID 0/1/5/10 support, TPM header, and AMI UEFI BIOS position MBD-X11SCV-Q for secure, serviceable deployments where external management is handled by the appliance design rather than an integrated BMC.

Why Choose the MBD-X11SCV-Q?

MBD-X11SCV-Q delivers a strong density-to-performance profile for standardized edge nodes by combining a mainstream LGA1151 CPU ecosystem with enterprise-aligned I/O in a Mini-ITX form factor. The design supports scalable rollouts across distributed sites, with straightforward PCIe 3.0 and storage expansion that keeps bill-of-materials controlled while maintaining reliable platform behavior for always-on infrastructure services.

Supermicro engineering emphasizes validated platform interoperability, long lifecycle availability, and pragmatic firmware and security foundations suited to modern data centre and edge standards, helping reduce integration risk in embedded and appliance builds.

Key Applications:

Industrial control and automation gateways
Retail kiosks and digital signage controllers
Branch office infrastructure services
Edge data logging and local analytics
Compact firewall and routing appliances

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your MBD-X11SCV-Q deployment, enabling accurate configuration planning for edge and embedded rollouts. For larger projects, bulk order discount options support cost-effective standardization across multiple sites.

Technical details of MBD-X11SCV-Q

CPU Socket:

H4 (LGA 1151)

Onboard Memory:

RAID Support:

Yes

CPU Manufacturer:

Intel

CPU Supported Type:

Core i9 Core i7 Core i5 Core i3 Pentium Celeron

Form Factor:

Mini-ITX

Chipset:

Intel Q370

RAM Maximum Capacity:

64GB

Max RAM Frequency :

2666MHz

RAM Slots:

2 SO-DIMM DDR4

PCIe Slots:

1 PCIe 3.0 x16

M.2 Slots:

1 PCIe 3.0 x1/CNVi M.2 2230 E-Key 1 PCIe 3.0 x4 M.2 2242, M.2 2280 M-Key

ECC Support:

Non-ECC

Onboard Network:

Ethernet

Suitability:

Server

Onboard CPU:

RAID Support:

Yes

Onboard Graphic:

Yes

Video Output:

1x DisplayPort 1x DVI-D 1x eDP (Embedded DisplayPort) 1x HDMI

USB Ports:

4x USB 3.2 Gen 2

Other Ports:

1x SuperDOM (Disk on Module) ports 1x TPM Header 4x COM Port

Trusted Platform Module (TPM):

Yes

BIOS:

AMI UEFI

Wi-Fi Support:

None

Bluetooth integrated:

None

Embedded:

Yes

Card Reader:

How long is the Warranty and how you can get technical support for MBD-X11SCV-Q

Warranty:	12 months (part) 36 months (labor)
Advanced replacement:	yes
RMA Url:	https://www.supermicro.com/en/support/rma/
Description:	120 days Advance Cross-Ship
