XS7680SE70094 Seagate Nytro 3332 7.68TB SAS 2.5" Server SSD

Get extra volume discount for XS7680SE70094 and save cash:

Quantity	Unit price
To 4	€2,109.00
To 9	€2,046.00 €2,109.00 (2.99% saved)
To 19	€2,004.00 €2,109.00 (4.98% saved)
From 20	€1,962.00 €2,109.00 (6.97% saved)

Product line:

Nytro

See all HDDs / SSDs

See other Seagate products

€2,109.00

Out of stock

Not available

Happyware Article Number:

SH028336-129257

Manufacturer Number:

XS7680SE70094

Brand:

Seagate

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

XS7680SE70094

High-Density 2.5in SAS Enterprise SSD for read-intensive tiers with the XS7680SE70094

The XS7680SE70094 is a 7.68TB Seagate Nytro 3332 internal enterprise SSD engineered for 2.5in SAS 12Gb/s server and storage platforms where predictable latency and sustained throughput are required. Designed around enterprise TLC NAND and a controller optimized for read-intensive duty cycles, it fits modern CPU-centric storage architectures by accelerating hot datasets without forcing a shift to NVMe backplanes.

In SAS-attached PCIe-based host environments, the XS7680SE70094 enables scalable expansion through standard HBA and RAID ecosystems, supporting dense drive counts and consistent serviceability. It delivers up to 2000MB/s sequential read and 240K IOPS 4K random read to stabilize virtualization datastores, database boot/log volumes, and VDI images, while 1 DWPD endurance (5 years) aligns with 24x7 enterprise tiering strategies and controlled write profiles.

Why Choose the XS7680SE70094?

The XS7680SE70094 provides an efficient density-to-performance balance for SAS infrastructures that prioritize compatibility, availability, and operational continuity. Its 12Gb/s interface supports incremental scaling in existing chassis, and the drive’s tuned read profile helps improve consolidation ratios by reducing storage wait states across shared compute clusters.

Seagate designs the Nytro portfolio with enterprise qualification, consistent firmware behavior, and lifecycle management suited to data centre standards, emphasizing reliability under continuous load, power efficiency at idle, and integration with established SAS monitoring and management practices.

Key Applications:

Server read-intensive storage tiers
Virtualization datastores
Database boot and log volumes
VDI boot images
24x7 enterprise storage pools
Secure data-at-rest deployments

At Happyware - Server Hardware you benefit from non-binding offers tailored to the XS7680SE70094 deployment profile and extended warranty options up to 6 years to improve planning security for long-lived SAS storage platforms.

Technical details of XS7680SE70094

Capacity:

7.68TB

Form Factor:

2.5"

Interface:

SAS

Speed Reading:

2000MB/s

Speed Writing:

1650MB/s

Total Bytes Written (TBW):

14000TB

Drive Writes Per Day (DWPD):

Suitability:

Server

Encryption:

Yes

Special features:

suitable for continuous operation (24/7)

Recording Process:

TLC

Height:

15mm

How long is the Warranty and how you can get technical support for XS7680SE70094

Warranty:	36 months (part)
RMA through customer:	yes
RMA Url:	https://www.seagate.com/support/warranty-and-replacements/
Description:	Items must be returned first for RMA. Advanced replacement is not available. No guaranteed delivery times specified. On-site service is not offered as standard. The warranty does not cover data loss. Regular data backups are recommended
