MZ-V7E500BW Samsung 970 EVO 500GB PCIe Gen 3 M.2 2280 Workstation SSD

High-Performance M.2 2280 NVMe SSD featuring PCIe Gen3 x4 client storage architecture with the MZ-V7E500BW

The MZ-V7E500BW is a Samsung 970 EVO Series internal NVMe SSD designed for workstation OS and application tiers where low latency and predictable responsiveness matter. In compact desktops and SFF platforms, the M.2 2280 M-Key form factor attaches directly to the PCIe Gen3 x4 fabric, reducing storage overhead compared with SATA and enabling a clean expansion profile for GPU-accelerated workstations.

Built on 500GB 3D NAND TLC with a 512MB DRAM cache, the MZ-V7E500BW sustains queue-depth-sensitive workloads such as local scratch, cache, and software build pipelines, delivering up to 3400 MB/s sequential reads and 2300 MB/s sequential writes with NVMe 1.3 command efficiency. For metadata-heavy operations, the MZ-V7E500BW reaches up to 370K/450K 4K random read/write IOPS, supporting rapid compiles, content creation asset indexing, and VM image staging within a client-class PCIe storage lane budget.

Why Choose the MZ-V7E500BW?

The MZ-V7E500BW provides an effective density-to-performance balance for endpoint fleets and engineering labs that require fast local storage without adding cabling, drive bays, or external controllers. With 300 TBW endurance, 1.5M hours MTBF, and low power draw, the MZ-V7E500BW fits scalable workstation rollouts where reliability, consistent boot behavior, and rapid application launch are operational requirements.

Samsung engineers the 970 EVO platform to align with modern data centre and enterprise endpoint standards by combining 3D NAND management, DRAM-backed mapping, and validated firmware behavior. The MZ-V7E500BW integrates Self-Encrypting Drive capabilities with AES-256, TCG Opal 2.0, and IEEE 1667 to support secure deployment policies across managed clients.

Key Applications:

• Workstation OS and application drive
• Local scratch and cache for content creation
• Software build and CI working directory
• Encrypted endpoint storage for lab systems
