LRC20Z500GG8 Kioxia EXCERIA G2 500GB PCIe Gen 3 M.2 2280 SSD

Get extra volume discount for LRC20Z500GG8 and save cash:

Quantity	Unit price
To 19	€62.88
To 49	€57.85 €62.88 (8% saved)
To 99	€53.45 €62.88 (15% saved)
From 100	€50.30 €62.88 (20.01% saved)

Product line:

EXCERIA G2

See all HDDs / SSDs

See other Kioxia products

€62.88

Out of stock

Happyware Article Number:

SH5M2990-483828

Manufacturer Number:

LRC20Z500GG8

Brand:

Kioxia

Are you a reseller?

Do you have questions about this product LRC20Z500GG8?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

LRC20Z500GG8

High-Performance M.2 NVMe Boot and Edge SSD featuring PCIe Gen3 x4 efficiency with the LRC20Z500GG8

The LRC20Z500GG8 is a compact M.2 2280 NVMe SSD engineered for OS/application drives in desktops, workstations, and light server boot volumes where consistent responsiveness matters more than high write endurance. Built on 3D TLC NAND with an SLC cache layer, it accelerates common boot and application access patterns while keeping latency predictable for mixed, everyday I/O.

Architecturally, the LRC20Z500GG8 leverages the PCIe Gen3 x4 NVMe pathway to remove SATA bottlenecks and to simplify platform integration on mainstream CPU chipsets that expose M-Key lanes. Sequential throughput up to 2100 MB/s read and 1700 MB/s write, plus up to 400k IOPS for 4K reads and writes, supports fast image deployments, paging, and local scratch without requiring an enterprise U.2 backplane. At 500GB, the LRC20Z500GG8 fits targeted boot and local data roles, while power features such as L1.2 low-power standby help edge nodes maintain thermal and power envelopes.

Why Choose the LRC20Z500GG8?

The LRC20Z500GG8 provides a practical density-to-performance balance for standardised fleet builds where PCIe Gen3 compatibility, predictable client-class NVMe behaviour, and straightforward serviceability are priorities. With 200 TBW endurance and 0.22 DWPD over 5 years, the LRC20Z500GG8 aligns to read-optimised and general-purpose profiles, enabling scalable rollouts across endpoints, edge appliances, and lab environments with controlled write amplification.

Kioxia designs storage around NAND process expertise and controller-level firmware discipline, delivering reliability aligned with modern data centre requirements such as TRIM support, efficient garbage collection, and compliance expectations including RoHS, supported by a 1.5M hours MTBF/MTTF target.

Key Applications:

OS and application boot volumes
Workstation local project storage
Edge appliance read-optimised caching
VDI endpoint and lab images
General-purpose NVMe client storage

At Happyware - Server Hardware you benefit from non-binding offers tailored to your deployment plan and extended warranty options up to 6 years, helping you standardise on the LRC20Z500GG8 with procurement clarity and long-term operational coverage.

Technical details of LRC20Z500GG8

Capacity:

500GB

Form Factor:

M.2 2280

Interface:

PCIe Gen 3

Speed Reading:

2100MB/s

Speed Writing:

1700MB/s

Total Bytes Written (TBW):

200TB

Drive Writes Per Day (DWPD):

0.22

Memory Components:

TLC

Special features:

L1.2 Low-Power-Standby SLC-Cache TRIM support 3D NAND Technology NVM Express (NVMe) Garbage Collection Technology

Power Consumption Operation:

3.5W

Certificates:

RoHS

Height:

2.23mm

How long is the Warranty and how you can get technical support for LRC20Z500GG8

Warranty:	36 months (part)
RMA through customer:	yes
RMA Url:	https://www.storrepair.com/kioxia/
Description:	Items must be returned first. No Advance replacement option. No delivery times are specificed.
