Intel Xeon W5-2545 12 Cores 24 Threads 4.7GHz E (LGA 4677) PK8071305502200 CPU

Single-Socket Workstation and Edge Server Processor Architecture with Intel Xeon W5-2545 (PK8071305502200)

The Intel Xeon W5-2545 is a Sapphire Rapids single-socket CPU for LGA4677 platforms, engineered for dense workstation compute and edge infrastructure where predictable latency and high I/O availability matter. With 12 cores and 24 threads, the Intel Xeon W5-2545 supports sustained mixed workloads such as CAD/EDA builds, content pipelines, and VM-based lab environments that require consistent per-core performance and enterprise-grade isolation.

For memory-bound engineering and virtualization scenarios, the Intel Xeon W5-2545 uses a 4-channel DDR5-4800 subsystem with ECC RDIMM support and scale-up headroom up to 2TB, enabling larger in-memory datasets and higher VM density while maintaining data integrity. Expansion is a primary design advantage: up to 64 PCIe 5.0 lanes (platform dependent) provide the bandwidth needed for modern GPU accelerators, high-speed NVMe storage backplanes, and low-latency NICs. Combined with AVX-512 and Intel AMX, the Intel Xeon W5-2545 is well aligned for CPU-based analytics, inference preprocessing, and vectorized simulation stages, while Intel DSA can offload data movement in storage and networking paths.

Why Choose the Intel Xeon W5-2545?

The Intel Xeon W5-2545 delivers a balanced density-to-performance profile for 1S deployments on W790-class platforms, simplifying capacity planning while maintaining enterprise reliability features such as VT-x/VT-d, AES-NI, and Total Memory Encryption. This makes the Intel Xeon W5-2545 a pragmatic choice for edge nodes and workstation fleets where PCIe 5.0 expansion and ECC memory are required without moving to multi-socket complexity.

Intel designs Xeon W processors to meet modern data centre expectations for security, validation, and platform stability, supporting long-life workstation and edge server configurations that must remain serviceable across multiple refresh cycles.

Key Applications:

• CAD/EDA build and simulation workstations
• Content creation and rendering pipelines
• Virtualization labs and small VM clusters
• Edge infrastructure services and consolidation
• CPU-based analytics and inference preprocessing

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your deployment requirements for the Intel Xeon W5-2545, and you can extend the warranty up to 6 years to protect long-life workstation and edge server rollouts.
