Intel Xeon Gold 6530 32 Cores 64 Threads 4GHz E (LGA 4677) BX807226530 Server CPU

High-Density Dual-Socket Server CPU Platform featuring PCIe 5.0 and DDR5 with the Intel Xeon Gold 6530

The Intel Xeon Gold 6530 (SKU BX807226530) is a 5th Gen Intel Xeon Scalable (Emerald Rapids-SP) processor for LGA4677, engineered for 2-socket servers that require predictable throughput, large memory footprints, and high-bandwidth I/O. With 32 cores and 64 threads, the Intel Xeon Gold 6530 targets consolidation and scale-up designs where per-node efficiency and platform longevity matter.

For memory-bound and mixed enterprise workloads, the Intel Xeon Gold 6530 provides an 8-channel DDR5 architecture up to 4800 MT/s with ECC and up to 4TB per socket, supporting high VM density and in-memory data processing while maintaining resiliency. PCIe 5.0 delivers up to 80 lanes to attach NVMe storage backplanes, high-speed networking, and accelerators without oversubscription, while 3 UPI links enable balanced 2-socket coherency for database, analytics, and general-purpose HPC nodes. Large cache resources (64MB L2 and 160MB L3) help sustain performance under multi-tenant and latency-sensitive conditions.

Why Choose the Intel Xeon Gold 6530?

The Intel Xeon Gold 6530 is well-suited for enterprise standardization where a single CPU SKU must scale from virtualization clusters to scale-up analytics, combining core density, DDR5 bandwidth, and PCIe 5.0 expansion in a 2-socket profile. The Intel Xeon Gold 6530 supports consistent capacity planning through defined power and platform requirements, enabling repeatable configurations across rack deployments.

Intel designs the Xeon Scalable family around validated server ecosystems, emphasizing RAS capabilities, ECC memory operation, and chipset-aligned platform controls for modern data centre requirements. The BX807226530 boxed processor is supplied without an included cooler, allowing thermal solutions to be selected per chassis and airflow design.

Key Applications:

• Private cloud virtualization hosts
• VM density and consolidation nodes
• Database and scale-up analytics
• General-purpose HPC compute
• PCIe Gen5 accelerator and high-speed I/O servers

At Happyware - Server Hardware you benefit from non-binding offers tailored to your configuration and deployment timeline for Intel Xeon Gold 6530 platforms, and from bulk order discount options when standardizing multiple nodes across clusters.
