Intel Xeon Gold 6330 28 Cores 56 Threads 3.1GHz P+ (LGA 4189) BX806896330 CPU

Enterprise 2-Socket Server CPU featuring Ice Lake-SP core density with the Intel Xeon Gold 6330 (BX806896330)

The Intel Xeon Gold 6330 is an Ice Lake-SP server processor designed for balanced compute in 2-socket platforms, aligning core density, cache hierarchy, and high-bandwidth I/O for consolidation-focused enterprise nodes. With 28 cores and 56 threads, the Intel Xeon Gold 6330 supports predictable scheduling for mixed virtualization and application tiers while maintaining strong per-socket throughput for scale-up services.

On the platform side, the Intel Xeon Gold 6330 enables DDR4 memory up to 2933 MT/s with ECC, allowing large memory footprints up to 6 TB per CPU where supported, which is decisive for in-memory databases and analytics nodes that prioritize capacity and integrity. PCIe 4.0 with up to 64 lanes per CPU improves attachment density for NVMe storage, smart NICs, and accelerators, while Intel VMD simplifies enterprise storage manageability. For data-plane and security requirements, AES-NI, Intel SGX, Total Memory Encryption, and TXT support workload isolation and compliance-oriented deployments. Three UPI links and 2S validation provide a clear scaling path for dual-socket architectures using Intel C621A/C627A/C629A server platforms.

Why Choose the Intel Xeon Gold 6330?

The Intel Xeon Gold 6330 is selected when IT teams need a pragmatic density-to-performance profile in standardized 2S racks, combining PCIe 4.0 expansion, high memory ceilings, and mature virtualization features. The Intel Xeon Gold 6330 also supports AVX-512 and DL Boost, making CPU-only inference and HPC preprocessing viable without complicating node design.

Intel engineers Xeon platforms for sustained operation under datacenter thermal and reliability constraints, with validated feature stacks spanning virtualization, secure boot/trust technologies, and platform manageability. This approach supports consistent lifecycle planning for enterprise fleets and aligns with modern server chipset ecosystems.

Key Applications:

• Virtualization and private cloud clusters
• Enterprise application servers
• Database and in-memory analytics
• CPU-only AI inference
• HPC preprocessing and simulation

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your configuration and procurement cycle, and you can extend the warranty up to 6 years to protect long-lived Intel Xeon Gold 6330 deployments in production environments.
