Intel Core i5-13500E 14 Cores 20 Threads 4.6GHz V (LGA 1700) CM8071505109403 Embedded CPU

*Picture may not be exactly the same as the product

Get extra volume discount for CM8071505109403 and save cash:

Quantity	Unit price
To 9	€320.00
To 19	€304.00 €320.00 (5% saved)
To 49	€298.00 €320.00 (6.88% saved)
From 50	€288.00 €320.00 (10% saved)

Product line:

Core i5

See all Server Processors

See other Intel products

€320.00

Out of stock

Not available

Happyware Article Number:

SH5C4336-877382

Manufacturer Number:

CM8071505109403

Brand:

Intel

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

Intel Core i5-13500E

Embedded and Edge Compute Processor Platform featuring hybrid Raptor Lake-S efficiency with the Intel Core i5-13500E

The Intel Core i5-13500E (SKU CM8071505109403) is a 13th Gen Raptor Lake-S embedded tray CPU for LGA1700 1S deployments where deterministic performance, long-life platform planning, and controlled power draw are required. Its hybrid core design with 14 cores and 20 threads supports mixed real-time control and general-purpose compute, while the 65W TDP profile simplifies thermal design in industrial PCs, edge gateways, and compact infrastructure nodes.

For memory architecture, the Intel Core i5-13500E enables up to 128GB DDR5-4800, allowing higher memory bandwidth per socket for virtualization and data-rich edge analytics; ECC capability is typically delivered by the selected platform chipset and board design. Expansion planning benefits from up to 20 PCIe lanes with PCIe 5.0/4.0 support for high-speed NICs, NVMe storage, and accelerators, and Intel VMD can streamline NVMe management and boot resiliency. Intel UHD Graphics 770 with support for up to 4 displays makes the Intel Core i5-13500E suitable for iGPU-driven digital signage and operator consoles without adding a discrete GPU.

Why Choose the Intel Core i5-13500E?

The Intel Core i5-13500E provides a balanced density-to-performance profile for 1S edge and embedded platforms, combining multi-thread throughput with enterprise virtualization features such as VT-x, VT-d, and EPT. With AES-NI and Intel Total Memory Encryption, the Intel Core i5-13500E aligns with security-first deployment logic, while PCIe 5.0 readiness supports scalable I/O growth across the service life.

Intel engineering emphasizes platform consistency, validation depth, and ecosystem compatibility across chipsets, firmware, and operating systems, supporting predictable integration into modern data centre and edge standards. As a tray CPU, the Intel Core i5-13500E is designed for system builders who control cooling, enclosure constraints, and lifecycle management.

Key Applications:

Industrial PC and control workloads
Edge virtualization hosts
Digital signage and multi-display endpoints
Secure branch and micro-edge infrastructure

At Happyware - Server Hardware you benefit from non-binding offers tailored to your Intel Core i5-13500E integration plan and an extended warranty of up to 6 years to protect long-life embedded deployments.

Technical details of Intel Core i5-13500E

L3 Cache:

24MB

Socket:

V (LGA 1700)

Threads:

Family:

Core

Code Name:

Raptor Lake-S

Generation:

13th

Cores:

Base Clock Speed:

2.4GHz

Boost Frequency:

4.6GHz

Max Supported Memory Speed:

4800 MHz

Memory Channels:

6-Channel

TDP (Thermal Design Power):

65W

ECC:

Yes

Suitability:

Embedded

Intergrated Graphics (iGPU):

Intel UHD Graphics 770

Cooler:

Boxed / Tray:

Tray

Supported Chipset:

H770 B660 B760 H610 H670 Q670 Q670E R680E W680 Z690 Z790 H610E

Hyper Threading:

Yes

64-Bit Support:

Yes

Serie:

Core i5

Front Side Bus (FSB):

300MHz

L2 Cache:

11.5MB

How long is the Warranty and how you can get technical support for Intel Core i5-13500E

Warranty:	12 months (part)
RMA Url:	https://supporttickets.intel.com/s/warrantyinfo?language=en_US
Description:	Items must be returned first before a replacement is sent. Intel does not offer on-site service as standard.
