W733-W30-AA01 Gigabyte Single Core Desktop 6NW733W30MR000AA01 Workstation Barebone

Product line:

Gigabyte W Series

See all Business & Office Workstation

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Not available

Happyware Article Number:

SE8B4443-479565

Manufacturer Number:

6NW733W30MR000AA01

Brand:

Gigabyte

Are you a reseller?

Do you have questions about this product 6NW733W30MR000AA01?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

W733-W30-AA01 Gigabyte

High-Performance Tower GPU Workstation engineered for single-accelerator PCIe Gen5 compute with the W733-W30-AA01 Gigabyte

The W733-W30-AA01 Gigabyte is a workstation-class tower platform built on the Intel W680 chipset for LGA1700 CPUs, supporting 12th/13th/14th Gen Intel Core processors up to 24 cores and 32 threads. It targets visual computing and single-GPU AI development by combining high per-core performance with a PCIe topology designed to sustain a multi-slot accelerator without constraining host-to-device bandwidth.

For memory integrity, the W733-W30-AA01 Gigabyte supports up to 128GB of DDR4-3200 ECC UDIMM across 4 DIMM slots in a dual-channel architecture, suitable for long-running CAD/CAE and content pipelines where data correctness matters. Expansion is centered on 2 PCIe Gen5 x16 slots, enabling a primary multi-slot GPU plus an additional high-bandwidth slot, while a PCIe Gen3 x4 slot supports ancillary I/O. Storage architecture is equally deliberate: up to 4 M.2 NVMe PCIe Gen4 x4 devices for low-latency scratch, datasets, and local models, complemented by 8 SATA ports and chassis support for up to 4 internal 3.5”/2.5” bays, with optional add-in paths for NVMe or SAS.

Why Choose the W733-W30-AA01 Gigabyte?

The W733-W30-AA01 Gigabyte balances workstation serviceability with enterprise-oriented manageability, delivering a strong density-to-performance profile for teams that need GPU acceleration on-premise or at the edge. With out-of-band control via BMC and a scalable I/O and storage layout, it integrates cleanly into remote deployment models while keeping the platform straightforward to standardize across departments.

Gigabyte designs the W-Series around stable component qualification, predictable thermal and power behavior, and adherence to modern data centre operational practices, including hardware monitoring, firmware-controlled management, and security integration options such as TPM support.

Key Applications:

Media and video production
CAD and CAE workflows
Single-GPU AI inference and development
Edge and remote workstation deployments
Local NVMe-backed dataset processing

At Happyware - Server Hardware you benefit from 24/7 Customer Service to support configuration and rollout planning for the W733-W30-AA01 Gigabyte, and you can extend the warranty up to 6 years to protect long-lived workstation fleets in production environments.

Technical details of W733-W30-AA01 Gigabyte

Type:

Tower

Suitability:

Workstation

CPU Socket:

V (LGA 1700)

CPU Family:

Core

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Core Desktop

Supported CPU Generation:

12th 13th 14th

Supported CPU Codename:

Alder Lake Raptor Lake Raptor Lake-E Refresh

Nodes:

RAM Type:

UDIMM

RAM Max. Total:

128GB

RAM Slots Total:

ECC Support:

ECC

Bays:

4x 2.5"/3.5" SATA

Hot-Swap:

RAID Support:

Yes

PCIe:

1x PCIe 3.0 x4 (x4 mode) 2x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

1x PCIe 3.0 x4 Unspecified 2x PCIe 5.0 x16 Unspecified

Onboard Network LAN:

1x RJ45 2.5 Gbps Intel I225

Onboard Network LAN Speed:

2.5 Gbps

Front I/O Ports:

Audio System status LED Storage Activity LED Power button with LED System Reset button Power status LED USB

Other Ports:

1x COM Port 2x Audio Port 3x Audio Port

IPMI / BMC integrated:

Yes

Chipset:

Intel W680

Power Supply Wattage:

850W

Redundant Power Supply:

Number of Power Supplies:

80 Plus Certificate:

80 Plus Gold

Quantity of Cooler:

Performance Class:

Enterprise-Class

Applications:

AI Inference Edge Computing Visual Computing GPU Server

Onboard CPU:

Onboard Graphic:

Aspeed AST2600

Graphics Manufacturer:

ASpeed

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Chassis Intrusion:

OS:

Windows 10 Windows 11

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C

How long is the Warranty and how you can get technical support for W733-W30-AA01 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
