TO46-SD3-LA07 Gigabyte
High-Density 40U Liquid-Cooled GPU Server architecture with TO46-SD3-LA07 Gigabyte for HGX B300 AI and HPC
The TO46-SD3-LA07 Gigabyte platform is a 40U liquid-cooled GPU server engineered around an NVIDIA HGX B300 baseboard with 8x SXM GPUs and an NVLink/NVSwitch fabric, paired with dual-socket Intel Xeon 6 (LGA4710) to balance accelerator throughput with strong host-side scheduling and I/O. This architecture targets GPU-saturated training and inference pipelines while maintaining deterministic thermal behavior under sustained, high-power utilization.
With 32 DDR5 DIMM slots (16 per CPU) across 8 memory channels per processor, TO46-SD3-LA07 Gigabyte supports high-capacity, ECC-protected host memory footprints for large model staging, feature stores, and CPU-side preprocessing. PCIe 5.0 expansion (4x FHHL x16) and OSFP-based SuperNIC networking enable low-latency scale-out fabrics, while front-access 8x 2.5" NVMe hot-swap bays plus dual M.2 NVMe provide a practical tiering model for dataset ingest, checkpointing, and fast local scratch without introducing hardware RAID dependencies.
Why Choose the TO46-SD3-LA07 Gigabyte?
TO46-SD3-LA07 Gigabyte is optimized for density-to-performance in modern AI clusters by tightly integrating HGX SXM acceleration, PCIe 5.0 I/O, and high-bandwidth OSFP networking into a serviceable 40U liquid-cooled design. It scales from single-node inference consolidation to multi-rack training, leveraging SuperNIC-based fabrics for east-west GPU communication and separate 10GbE management for operational separation.
Gigabyte engineering emphasizes platform integrity for continuous enterprise operation, combining robust BMC remote management (IPMI via AST2600), DC bus bar power integration for data centre power architectures, and optional TPM 2.0 support to align with security and compliance requirements.
Key Applications:
- Large-scale AI training (HGX SXM)
- AI inference consolidation
- GPU-accelerated HPC simulation
- Scale-out AI clusters (InfiniBand XDR or 400GbE)
- High-throughput data preprocessing
At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your TO46-SD3-LA07 Gigabyte configuration and deployment plan, supported by 24/7 customer service to keep enterprise procurement and rollout schedules on track.
Technical details of TO46-SD3-LA07 Gigabyte
How long is the Warranty and how you can get technical support for TO46-SD3-LA07 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
