S183-SH0-AAJ1 Gigabyte Dual Xeon CPU Max 1U 6NS183SH0DR000ABJ1 Server Barebone
Do you have a major deal consisting of various components? Then you're at the right place!
We offer you the best prices for your purchase:
- - If you already have an account with us, please log in. If you don't have an account, you can apply for one here.
- - simply collect your required items in the desired quantity in CART, and click the 'GET QUOTATION' button. and you're done!
- - You will receive your offer within the next 24 hours on working days.
Gigabyte S Series
Do you have questions about this product 6NS183SH0DR000ABJ1?
S183-SH0-AAJ1 Gigabyte
High-Density 1U NVMe Storage Server Barebone featuring PCIe Gen5 E1.S flash with the S183-SH0-AAJ1 Gigabyte platform
The S183-SH0-AAJ1 Gigabyte barebone is a 1U storage-focused architecture designed for latency-sensitive, high-throughput all-flash tiers where rack-unit efficiency and serviceability are mandatory. Built on the Intel C741 chipset with dual LGA4677 sockets, it supports 4th/5th Gen Intel Xeon Scalable processors (Sapphire/Emerald Rapids) or Xeon CPU Max, enabling balanced core density and memory bandwidth for storage services, database acceleration, and NVMe-oF target roles.
With 32x DDR5 RDIMM ECC slots (8-channel per CPU), the S183-SH0-AAJ1 Gigabyte platform scales memory to sustain deep I/O queues, metadata-heavy workloads, and caching layers without starving the front-end. The key design point is 32x front hot-swap E1.S NVMe bays on PCIe Gen5, delivering consistent parallelism and simplified drive replacement at scale, while 2x M.2 (22110/2280) bays isolate boot media from the data plane. Three PCIe Gen5 expansion slots via risers support add-in RAID or fabric options; NVMe RAID can be implemented via optional controllers, including Graid SupremeRAID models.
Why Choose the S183-SH0-AAJ1 Gigabyte?
The S183-SH0-AAJ1 Gigabyte design concentrates Gen5 NVMe density into 1U without compromising operational control, aligning with enterprise rollouts that demand predictable performance per rack, rapid service access, and standardized remote management. It is well-suited for scaling-out storage nodes where uniform topology, hot-swap maintenance, and redundant power are prerequisites.
Gigabyte engineering prioritizes data centre compatibility and lifecycle resilience, combining redundant 80 PLUS Titanium hot-swap power, ASPEED AST2600 BMC with IPMI and HTML5 KVM, and a UEFI-based platform to support repeatable provisioning and secure operations across large clusters.
Key Applications:
- Software-defined storage NVMe tiers
- NVMe-oF target nodes
- High-IOPS databases
- Analytics and indexing platforms
- Private and hybrid cloud storage
- HPC metadata and cache nodes
At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your deployment goals for the S183-SH0-AAJ1 Gigabyte configuration, and you can extend the warranty up to 6 years to protect long-term platform availability in production environments.
Technical details of S183-SH0-AAJ1 Gigabyte
How long is the Warranty and how you can get technical support for S183-SH0-AAJ1 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
