R284-S92-AAJ1 Gigabyte Dual Xeon 6700 2U 6NR284S92DR000AAJ1 Server Barebone

Get extra volume discount for 6NR284S92DR000AAJ1 and save cash:

Quantity	Unit price
	€4,092.48
To 4	€4,011.00 €4,092.48 (1.99% saved)
To 9	€3,929.00 €4,092.48 (3.99% saved)
From 10	€3,847.00 €4,092.48 (6% saved)

Product line:

Gigabyte R Series

See all Rackmount Servers 2U

See other Gigabyte products

€4,092.48

In stock

Happyware Article Number:

SE7B9022-604441

Manufacturer Number:

6NR284S92DR000AAJ1

Brand:

Gigabyte

Are you a reseller?

Do you have questions about this product 6NR284S92DR000AAJ1?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R284-S92-AAJ1 Gigabyte

High-Density 2U Dual-Socket Storage and Expansion Platform with R284-S92-AAJ1 Gigabyte

The R284-S92-AAJ1 Gigabyte barebone is a 2U dual-socket rack server platform engineered around Intel Xeon 6 processors (LGA4710) to balance core density with sustained I/O, enabling Granite Rapids or Sierra Forest deployment profiles up to 350W TDP per CPU. The R284-S92-AAJ1 Gigabyte memory subsystem scales through 32 DDR5 ECC RDIMM/MRDIMM slots with 8-channel per CPU bandwidth, supporting large in-memory datasets while preserving enterprise error correction and predictable latency under mixed virtualization and storage services.

For storage-centric builds, the R284-S92-AAJ1 Gigabyte exposes a Gen5-ready front backplane with 24 x 2.5in hot-swap bays optimized for NVMe (PCIe 5.0 x4 per drive), with optional SATA or SAS-4 integration via add-in controllers to align media tiers with cost and endurance targets. Gen5 expansion is maintained through multiple PCIe 5.0 x16 FHHL slots suitable for high-throughput NICs, NVMe RAID/HBA cards, or accelerator-class add-ins, while internal M.2 Gen5 options provide a clean boot and caching topology without consuming front bays.

Why Choose the R284-S92-AAJ1 Gigabyte?

The R284-S92-AAJ1 Gigabyte delivers a practical density-to-performance profile for scale-out infrastructure by combining dual-socket compute, high DIMM counts, and PCIe Gen5 lane availability in a serviceable 2U chassis. This architecture supports predictable growth from single-node storage targets to clustered NVMe nodes, with redundant Titanium power and out-of-band management designed for continuous enterprise operations.

Gigabyte designs the R Series with a data centre-first engineering approach, focusing on validated thermal and power envelopes, standards-aligned management via AST2600 BMC with IPMI/HTML5 KVM, and modular I/O options such as OCP NIC 3.0 to simplify fleet consistency and lifecycle maintenance.

Key Applications:

NVMe storage nodes and software-defined storage
Hybrid and private cloud virtualization
Scale-out infrastructure clusters
High-IOPS database tiers
Data analytics and ingestion pipelines

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your R284-S92-AAJ1 Gigabyte configuration goals and an extended warranty of up to 6 years to protect long-term platform deployments.

Technical details of R284-S92-AAJ1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

E2 (LGA 4710)

CPU Family:

Xeon

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon 6700 Xeon 6500

Supported CPU Generation:

6th

Supported CPU Codename:

Sierra Forest Granite Rapids

Nodes:

RAM Type:

RDIMM MRDIMM

RAM Max. Total:

8TB

RAM Slots Total:

ECC Support:

ECC

Bays:

2x 2.5" HotSwap SATA, SAS 24x 2.5" HotSwap NVMe, SATA, SAS

Hot-Swap:

Yes

PCIe:

3x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

3x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps Intel I350-AM2

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

NMI button System status LED Storage Activity LED LAN Activity LED Power button with LED System Reset button USB UID button with LED

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

2000W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

350W

Applications:

Networking Hybrid/Private Cloud Server Enterprise

Onboard CPU:

Onboard Graphic:

Aspeed AST2600

Graphics Manufacturer:

ASpeed

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Certificates:

80 Plus Titanium

Chassis Intrusion:

OS:

Citrix Hypervisor (formerly XenServer) Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C

How long is the Warranty and how you can get technical support for R284-S92-AAJ1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
