R284-S91-AAJ2 Gigabyte Dual Xeon 6500 2U 6NR284S91DR000AAJ2 Server Barebone

Product line:

Gigabyte R Series

See all Rackmount Servers 2U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Happyware Article Number:

SH4B3543-330215

Manufacturer Number:

6NR284S91DR000AAJ2

Brand:

Gigabyte

Are you a reseller?

Do you have questions about this product 6NR284S91DR000AAJ2?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R284-S91-AAJ2 Gigabyte

High-Density 2U Dual-Socket NVMe Storage Server Architecture with the R284-S91-AAJ2 Gigabyte

The R284-S91-AAJ2 Gigabyte is a 2U, dual-socket rack server designed around Intel Xeon 6 platforms (Granite Rapids / Sierra Forest) to deliver balanced compute and storage throughput for data-intensive enterprise tiers. With up to 2 CPUs at 350W, the platform targets high core density and predictable performance scaling while maintaining serviceability for always-on environments.

To sustain consolidation ratios, the R284-S91-AAJ2 Gigabyte provides DDR5 ECC RDIMM/MRDIMM support across 32 DIMM slots, enabling large-memory virtualization, in-memory databases, and analytics pipelines with strong RAS characteristics. PCIe Gen5 I/O underpins a low-latency storage and expansion fabric: 16 front-accessible E3.S NVMe hot-swap bays plus additional 2.5in SAS/SATA bays align well with NVMe tiering and software-defined storage layouts. Three internal PCIe Gen5 M.2 slots simplify mirrored boot or local cache design, while CXL-ready expansion options improve future composability. For networking and attach, dual OCP NIC 3.0 SFF slots (PCIe 5.0 x16 each) and an additional PCIe 5.0 x16 FHHL slot support high-speed NICs or accelerator-class cards where needed.

Why Choose the R284-S91-AAJ2 Gigabyte?

The R284-S91-AAJ2 Gigabyte prioritizes density-to-performance by combining dual Xeon 6 compute, high-memory ceilings, and PCIe Gen5 NVMe bandwidth in a serviceable 2U footprint. This architecture supports scale-out nodes with consistent I/O behavior, redundant power, and remote lifecycle control for standardized deployments.

Gigabyte engineering emphasizes platform validation, tool-less service access, and modern management via an AST2600 BMC with IPMI, aligning the R284-S91-AAJ2 Gigabyte with operational requirements in virtualized, storage, and analytics clusters.

Key Applications:

Software-defined storage and NVMe tiering
Hybrid/private cloud virtualization hosts
Database and low-latency analytics
High-throughput NVMe caching nodes

At Happyware - Server Hardware you benefit from non-binding offers tailored to your configuration targets for the R284-S91-AAJ2 Gigabyte and from extended warranty options up to 6 years to protect long-term platform standardization.

Technical details of R284-S91-AAJ2 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

E2 (LGA 4710)

CPU Family:

Xeon

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon 6700 Xeon 6500

Supported CPU Generation:

6th

Supported CPU Codename:

Sierra Forest Granite Rapids

Nodes:

RAM Type:

RDIMM MRDIMM

RAM Max. Total:

8TB

RAM Slots Total:

ECC Support:

ECC

Bays:

2x 2.5" HotSwap SATA, SAS 16x E3.S HotSwap NVMe

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

1x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

1x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps Intel I350-AM2

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

NMI button System status LED Storage Activity LED LAN Activity LED Power button with LED System Reset button USB UID button with LED

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

2000W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

350W

Applications:

Networking Hybrid/Private Cloud Server Storage Enterprise

Onboard CPU:

Onboard Graphic:

Aspeed AST2600

Graphics Manufacturer:

ASpeed

Certificates:

80 Plus Titanium

Chassis Intrusion:

OS:

Citrix Hypervisor (formerly XenServer) Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C

How long is the Warranty and how you can get technical support for R284-S91-AAJ2 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
