R283-Z94-AAD2 Gigabyte Dual EPYC 9004 2U 6NR283Z94DR000ACD2 Server Barebone

Product version:

Rev-3.x

Product line:

Gigabyte R Series

See all Rackmount Servers 2U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Happyware Article Number:

SH8B1718-163421

Manufacturer Number:

6NR283Z94DR000ACD2

Brand:

Gigabyte

Are you a reseller?

Do you have questions about this product 6NR283Z94DR000ACD2?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R283-Z94-AAD2 Gigabyte

High-Density 2U Dual-Socket AMD EPYC Rack Server Platform with Hybrid Storage Architecture using the R283-Z94-AAD2 Gigabyte

The R283-Z94-AAD2 Gigabyte is a 2U, single-node rack server barebone engineered around the AMD EPYC SP5 platform for scalable compute and mixed I/O consolidation. It supports 2 x AMD EPYC 9005/9004 (Turin/Genoa) processors, enabling high core density for virtualisation hosts and scale-up enterprise services while maintaining predictable platform behaviour under sustained load.

Memory architecture is optimised for large working sets with 24 x DDR5 RDIMM ECC slots across 12 channels per CPU, supporting high-capacity configurations up to 6TB. PCIe 5.0 expansion is exposed through 4 x x16 FHHL slots for high-throughput adapters and accelerator-class peripherals, complemented by 2 x OCP NIC 3.0 PCIe 5.0 x16 slots for modern network fabrics. Storage is designed as a hybrid tier: front bays combine up to 4 x Gen5 NVMe (in NVMe/SAS/SATA-capable positions) with additional SATA/SAS capacity bays, plus rear 2.5" SATA/SAS, while SAS/RAID is enabled via add-in HBA/RAID controllers. OS boot can be isolated on up to 3 x M.2 NVMe devices.

Why Choose the R283-Z94-AAD2 Gigabyte?

The R283-Z94-AAD2 Gigabyte delivers a balanced density-to-performance profile for private cloud and consolidated enterprise workloads by aligning SP5 compute, DDR5 bandwidth, and PCIe 5.0 I/O in a serviceable 2U chassis. The R283-Z94-AAD2 Gigabyte also supports scalable networking via OCP NIC 3.0 and maintains availability targets with redundant 1600W hot-swap power and out-of-band management for controlled operations at rack scale.

Gigabyte designs this platform with data centre operational consistency in mind, combining an AST2600 BMC for IPMI remote KVM, server-grade signal integrity for PCIe 5.0, and component choices aligned to modern power and management standards. The R283-Z94-AAD2 Gigabyte integrates cleanly into standard provisioning and security practices, including TPM header support for measured-boot policies.

Key Applications:

Hybrid/private cloud virtualisation hosts
Enterprise database and in-memory services
Mixed NVMe and SAS/SATA storage consolidation
Network functions and edge services

At Happyware - Server Hardware you benefit from non-binding offers tailored to your deployment requirements for the R283-Z94-AAD2 Gigabyte, and you can extend the warranty up to 6 years to align platform lifecycle coverage with enterprise procurement and support plans.

Technical details of R283-Z94-AAD2 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

SP5 (LGA 6096)

CPU Family:

EPYC

Supported CPU Manufacturer:

AMD

Supported CPU Type:

EPYC 9004 EPYC 9005

Supported CPU Generation:

4th 5th

Supported CPU Codename:

Genoa Turin

Nodes:

RAM Type:

RDIMM

RAM Max. Total:

6TB

RAM Slots Total:

ECC Support:

ECC

Bays:

2x 2.5" HotSwap SATA, SAS 4x 2.5"/3.5" HotSwap NVMe, SATA, SAS 8x 2.5"/3.5" HotSwap SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

4x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

4x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps I350-AM2

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

LED Indicators USB

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

1600W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Platinum

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

500W

Applications:

Networking Hybrid/Private Cloud Server Enterprise

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Certificates:

80 Plus Platinum

Chassis Intrusion:

OS:

Citrix Hypervisor (formerly XenServer) Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server

How long is the Warranty and how you can get technical support for R283-Z94-AAD2 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
