R283-Z90-AAD1 Gigabyte Dual EPYC 9004 2U 6NR283Z90DR000ACD1 Server Barebone
Do you have a major deal consisting of various components? Then you're at the right place!
We offer you the best prices for your purchase:
- - If you already have an account with us, please log in. If you don't have an account, you can apply for one here.
- - simply collect your required items in the desired quantity in CART, and click the 'GET QUOTATION' button. and you're done!
- - You will receive your offer within the next 24 hours on working days.
Rev-3.x
Product line:Gigabyte R Series
Do you have questions about this product 6NR283Z90DR000ACD1?
R283-Z90-AAD1 Gigabyte
High-Density 2U NVMe Storage and Compute Platform with PCIe Gen5 Expansion using the R283-Z90-AAD1 Gigabyte
The R283-Z90-AAD1 Gigabyte (SKU: 6NR283Z90DR000ACD1) is a 2U rack server barebone engineered for dual-socket AMD EPYC 9005/9004 (SP5) deployments where CPU throughput and low-latency I/O must scale together. With up to 192 cores per system and a design tolerance up to 400W TDP per CPU, the platform targets high-IOPS tiers, virtualisation hosts, and mixed-service nodes that require deterministic performance under consolidation.
The R283-Z90-AAD1 Gigabyte couples DDR5 ECC RDIMM capacity across 24 DIMM slots with PCIe 5.0 connectivity to keep memory bandwidth and device lanes aligned for modern accelerators, high-speed NICs, and NVMe fabrics. Its 12+4 hot-swap drive architecture supports front NVMe/SAS/SATA media plus rear SAS/SATA bays for tiering or mirrored OS volumes, while 3 onboard M.2 NVMe sockets provide compact boot or cache devices. Riser-based PCIe Gen5 x16 slots and dual OCP NIC 3.0 SFF slots simplify network upgrades without sacrificing front-bay density.
Why Choose the R283-Z90-AAD1 Gigabyte?
The R283-Z90-AAD1 Gigabyte delivers a balanced density-to-performance profile by combining dual EPYC compute, DDR5 scalability, and a storage backplane designed for mixed media and serviceability. Redundant 1600W hot-swap PSUs, dedicated management networking, and a clear I/O topology enable predictable scaling from single-node storage servers to repeatable rack-level builds.
Gigabyte designs this platform around data centre operability: modular risers, standardised OCP 3.0 options, and ASPEED AST2600 BMC management with IPMI and HTML5 KVM for remote lifecycle control. The result is an enterprise-aligned barebone optimised for uptime, consistent thermals, and straightforward field maintenance.
Key Applications:
- NVMe storage nodes for high-IOPS databases
- Object and block storage tiers
- Virtualisation and private cloud clusters
- Content delivery and caching nodes
- PCIe Gen5 I/O consolidation hosts
At Happyware - Server Hardware you benefit from non-binding offers tailored to your deployment bill of materials for the R283-Z90-AAD1 Gigabyte, enabling fast procurement alignment for scale-out projects. For larger rollouts, bulk order discounts support predictable budgeting across multi-node builds.
Technical details of R283-Z90-AAD1 Gigabyte
How long is the Warranty and how you can get technical support for R283-Z90-AAD1 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
