R265-DG3-AS1 Gigabyte
High-Density 2U NVMe Storage Node engineered for AMD EPYC 9006 with the R265-DG3-AS1 Gigabyte platform
The R265-DG3-AS1 Gigabyte is a 2U rack server barebone designed as an enterprise all-flash NVMe node, combining a single-socket AMD EPYC 9006 “Venice” SP7 platform with a 20-bay E3.S hot-swap topology for predictable low-latency storage tiers. The CPU architecture scales to high core counts and high TDP envelopes, enabling storage services, data reduction, and control-plane processing without requiring a dual-socket footprint.
With 16 DDR5 DIMM slots and a 16-channel memory architecture, the R265-DG3-AS1 Gigabyte supports large memory footprints for metadata-heavy NVMe pools, caching layers, and SDS control services. PCIe expansion is aligned to next-generation fabrics: a PCIe 6.0 x16 full-height, full-length slot supports high-speed NICs or GPU-class accelerators for inline analytics, while dual onboard 1GbE and a dedicated BMC/IPMI management port provide baseline connectivity and out-of-band control. Boot resilience is handled via dual internal M.2 NVMe (PCIe 4.0 x2), isolating OS media from the 20 E3.S NVMe data plane.
Why Choose the R265-DG3-AS1 Gigabyte?
The R265-DG3-AS1 Gigabyte delivers a strong density-to-performance ratio by pairing 20 direct NVMe ports with a single-socket EPYC 9006 compute domain, reducing platform complexity while maintaining scale-out consistency. This architecture fits standardized 2U storage sled deployments, supports predictable serviceability via hot-swap bays and redundant power, and enables growth through PCIe 6.0 expansion for higher-speed networking as cluster bandwidth requirements increase.
Gigabyte applies a data-centre engineering focus with serviceable mechanical design, IPMI-based lifecycle management, and power-efficient redundant PSU options aligned to modern rack power and reliability expectations.
Key Applications:
- Software-defined storage (NVMe all-flash tiers)
- Private cloud storage and compute nodes
- High-IOPS databases and log analytics
- Virtualization datastores
- Edge core services with centralized management
At Happyware - Server Hardware you benefit from Non-Binding Offers tailored to your R265-DG3-AS1 Gigabyte configuration goals and an Extended Warranty option up to 6 years to secure long-term platform availability for production clusters.
Technical details of R265-DG3-AS1 Gigabyte
How long is the Warranty and how you can get technical support for R265-DG3-AS1 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
