R264-SG5-AAJ1 Gigabyte
High-Performance 2U NVMe Storage Server Barebone featuring PCIe Gen5 E3.S density with the R264-SG5-AAJ1 Gigabyte
The R264-SG5-AAJ1 Gigabyte is a 2U rack server barebone engineered as a high-IOPS NVMe storage node, pairing a single-socket Intel Xeon 6 platform with a 28-bay E3.S PCIe Gen5 front plane. It targets database, analytics, and software-defined storage tiers where deterministic latency, queue depth handling, and serviceability are primary design requirements.
Built around Granite Rapids or Sierra Forest (Xeon 6500/6700) with up to 350W TDP, the R264-SG5-AAJ1 Gigabyte balances core count and I/O by aligning CPU lane selection to full feature enablement, including large PCIe lane budgets for storage and fabric expansion. The memory subsystem uses 8-channel DDR5 ECC Registered with 16 DIMM slots, supporting RDIMM or MRDIMM up to 4TB, enabling high cache hit rates and consistent performance under mixed read/write workloads. Storage is optimized for scale-out NVMe: 28 hot-swap E3.S bays on PCIe Gen5 x4 (lane dependent), plus dual PCIe 5.0 x2 M.2 slots for OS isolation. Expansion includes a PCIe 5.0 x16 FHFL slot designated for optional single-GPU acceleration and an OCP NIC 3.0 SFF slot for high-bandwidth networking.
Why Choose the R264-SG5-AAJ1 Gigabyte?
The R264-SG5-AAJ1 Gigabyte delivers a high density-to-performance ratio by concentrating Gen5 NVMe bandwidth, resilient power, and out-of-band management into a serviceable 2U footprint. It scales cleanly in private or hybrid cloud deployments where predictable I/O, flexible networking, and straightforward node replication are critical to uptime and capacity growth.
Gigabyte applies data-center-first engineering with redundant hot-swap power (up to 2000W, 80 PLUS Titanium), AST2600 BMC remote management with IPMI and HTML5 KVM, and platform controls that align with enterprise operational standards.
Key Applications:
- NVMe-backed databases
- Analytics and data warehousing tiers
- Software-defined storage nodes
- Private and hybrid cloud NVMe pools
- Low-latency logging and ingest
At Happyware - Server Hardware you benefit from non-binding offers tailored to your NVMe tiering and network fabric requirements, and from an extended warranty of up to 6 years to secure long lifecycle operation for the R264-SG5-AAJ1 Gigabyte in production clusters.
Technical details of R264-SG5-AAJ1 Gigabyte
How long is the Warranty and how you can get technical support for R264-SG5-AAJ1 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
