R184-S94-AAV1 Gigabyte Dual Xeon 6 SoC 1U 6NR184S94DR000AAV1 Server Barebone

Product line:

Gigabyte R Series

See all Rackmount Servers 1U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Not available

Happyware Article Number:

SH9B1424-169234

Manufacturer Number:

6NR184S94DR000AAV1

Brand:

Gigabyte

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R184-S94-AAV1 Gigabyte

High-Performance 1U NVMe Storage and Compute Node featuring PCIe Gen5 I/O with the R184-S94-AAV1 Gigabyte

R184-S94-AAV1 Gigabyte is a 1U dual-socket barebone engineered for high-I/O NVMe consolidation, combining Intel Xeon 6 (Granite Rapids/Sierra Forest) compute with a front-accessible PCIe Gen5 storage plane optimized for software-defined storage and latency-sensitive data tiers. The dual-CPU platform supports up to 350W per socket and scales core density for virtualization hosts while keeping a compact footprint for rack-constrained deployments.

R184-S94-AAV1 Gigabyte implements DDR5 with 8-channel memory per CPU across 32 DIMM slots using ECC Registered RDIMM/MRDIMM, enabling large in-memory caching and predictable performance under mixed I/O and compute. For storage, 16 front hot-swap E3.S NVMe bays connect via a PCIe Gen5 x4 backplane to sustain high queue-depth throughput, while up to 3 internal M.2 NVMe Gen5 devices support resilient boot or local tiering. Expansion and network paths are aligned to modern fabrics through 2 PCIe 5.0 x16 FHHL slots and dual OCP 3.0 SFF PCIe 5.0 x16 NIC slots, with BMC-based remote management for lights-out operations.

Why Choose the R184-S94-AAV1 Gigabyte?

R184-S94-AAV1 Gigabyte delivers an efficient density-to-performance ratio by pairing dual-socket Xeon 6 compute with a 16-bay E3.S Gen5 NVMe front plane, reducing node count for scale-out storage, cloud clusters, and edge aggregation. R184-S94-AAV1 Gigabyte supports enterprise reliability via hot-swap storage and redundant power, and it scales cleanly with PCIe Gen5 lanes and OCP networking to match evolving bandwidth requirements.

Gigabyte designs the R Series around serviceability, standardized management, and data center compatibility, including AST2600 BMC with IPMI/HTML5 KVM, validated high-efficiency redundant power, and security options such as a TPM 2.0 header. R184-S94-AAV1 Gigabyte aligns these elements into a predictable operational profile for fleet deployments.

Key Applications:

Software-defined storage (SDS) nodes
NVMe data-tier acceleration
Virtualization and private/hybrid cloud
High-throughput edge storage gateways
Network function virtualization (NFV) infrastructure

At Happyware - Server Hardware you benefit from non-binding offers tailored to your exact R184-S94-AAV1 Gigabyte configuration and project timeline, enabling fast procurement alignment for rollout or expansion. For larger deployments, bulk order discounts support consistent node standardization across clusters.

Technical details of R184-S94-AAV1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

E2 (LGA 4710)

CPU Family:

Xeon

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon 6 SoC Xeon 6700 Xeon 6500

Supported CPU Generation:

6th

Supported CPU Codename:

Sierra Forest Granite Rapids

Nodes:

RAM Type:

RDIMM MRDIMM

RAM Max. Total:

8TB

RAM Slots Total:

ECC Support:

ECC

Bays:

16x E3.S HotSwap NVMe

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

2x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

2x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps I350-AM2

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

LED Indicators USB

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

1600W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

350W

Applications:

Networking Hybrid/Private Cloud Server Enterprise

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Certificates:

80 Plus Titanium

Chassis Intrusion:

OS:

Citrix Hypervisor (formerly XenServer) Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server

How long is the Warranty and how you can get technical support for R184-S94-AAV1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
