R184-S90-AAV1 Gigabyte Dual Xeon 6 SoC 1U 6NR184S90DR000AAV1 Server Barebone
Do you have a major deal consisting of various components? Then you're at the right place!
We offer you the best prices for your purchase:
- - If you already have an account with us, please log in. If you don't have an account, you can apply for one here.
- - simply collect your required items in the desired quantity in CART, and click the 'GET QUOTATION' button. and you're done!
- - You will receive your offer within the next 24 hours on working days.
Gigabyte R Series
Do you have questions about this product 6NR184S90DR000AAV1?
R184-S90-AAV1 Gigabyte
High-Density 1U Dual-Socket Intel Xeon 6 Rack Server Barebone with PCIe Gen5 I/O, the R184-S90-AAV1 Gigabyte Platform
The R184-S90-AAV1 Gigabyte barebone is a 1U, dual-socket Intel Xeon 6 platform engineered for virtualization-heavy private cloud and density-optimized compute where core count, memory bandwidth, and PCIe Gen5 expansion must scale together. With support for Granite Rapids or Sierra Forest families (Xeon 6500/6700 series), the system enables high core density per rack unit while maintaining enterprise-class management and serviceability.
R184-S90-AAV1 Gigabyte is built around a balanced memory and I/O architecture: 32 DDR5 DIMM slots deliver 8-channel per CPU bandwidth with ECC RDIMM/MRDIMM support for capacity-driven consolidation. PCIe Gen5 connectivity is extended through riser-based full-height x16 slots and dual OCP NIC 3.0 SFF PCIe 5.0 x16 bays, enabling consistent east-west throughput and adaptable fabric choices. Storage is optimized for mixed tiers using front hot-swap bays that can be configured for PCIe Gen5 x4 NVMe, SATA 6Gb/s, or SAS-4 24Gb/s backplanes, with internal M.2 NVMe Gen5 options for resilient boot segregation.
Why Choose the R184-S90-AAV1 Gigabyte?
The R184-S90-AAV1 Gigabyte platform targets high VM density and mixed workload consolidation by combining 1U efficiency with dual-socket scalability, high DDR5 capacity ceilings, and PCIe Gen5 lanes for modern NICs, accelerators, and NVMe. Redundant Titanium PSUs, hot-swap service paths, and a BMC-based remote operations stack support standardized rollout and predictable lifecycle management across clustered deployments.
Gigabyte designs R-series servers with a datacentre-first engineering approach focused on signal integrity for PCIe Gen5, validated thermal behavior in dense racks, and management consistency via ASPEED AST2600 with IPMI and HTML5 KVM, aligning the platform with modern operations and compliance requirements.
Key Applications:
- Private cloud and virtualization clusters
- Hybrid cloud compute nodes
- Enterprise application consolidation
- High-density edge datacentres
- NVMe-focused storage tiers
At Happyware - Server Hardware you benefit from non-binding offers tailored to your configuration goals for the R184-S90-AAV1 Gigabyte and the option to extend the warranty up to 6 years to protect long-term datacentre deployments.
Technical details of R184-S90-AAV1 Gigabyte
How long is the Warranty and how you can get technical support for R184-S90-AAV1 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
