R184-A90-AAJ1 Gigabyte Dual Xeon 6 SoC 1U 6NR184A90DR000AAJ1 Server Barebone

Product line:

Gigabyte R Series

See all Rackmount Servers 1U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Happyware Article Number:

SH1B3506-974962

Manufacturer Number:

6NR184A90DR000AAJ1

Brand:

Gigabyte

Are you a reseller?

Do you have questions about this product 6NR184A90DR000AAJ1?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R184-A90-AAJ1 Gigabyte

High-Density 1U Dual-Socket Rack Server Barebone with Gen5 I/O and Hybrid Front-Drive Backplane using the R184-A90-AAJ1 Gigabyte

The R184-A90-AAJ1 Gigabyte is a 1U R-Series barebone engineered for dual-socket Intel Xeon 6 (Socket BR LGA7529), aligning high core density with PCIe Gen5 bandwidth for virtualization and private cloud compute. Support for Granite Rapids / Xeon 6900 with P-cores and up to 500W per CPU enables consolidation of CPU-intensive services while maintaining predictable thermal and power behavior in standard enterprise racks.

Memory architecture is optimized for throughput and capacity: DDR5 ECC Registered across 24 DIMM slots with 12-channel per CPU, scaling to 6TB with RDIMM or MRDIMM options. The R184-A90-AAJ1 Gigabyte uses a hybrid front backplane with 4 x 3.5-inch hot-swap bays that can be configured for NVMe PCIe Gen5 x4 or SATA/SAS-4 with the appropriate controller, plus 3 x M.2 NVMe PCIe Gen5 for boot or tiered caching. Expansion is delivered through 2 x PCIe 5.0 x16 FHHL slots for accelerators or high-speed I/O, complemented by dual OCP NIC 3.0 SFF PCIe 5.0 x16 for scalable network fabrics.

Why Choose the R184-A90-AAJ1 Gigabyte?

The R184-A90-AAJ1 Gigabyte provides a balanced density-to-performance profile for mixed compute and storage nodes, combining Gen5 lanes, flexible front-bay media, and enterprise manageability in a compact 1U footprint. Redundant hot-swap power up to 2000W and ECC memory support help standardize deployments that must scale consistently across clusters and edge-infrastructure tiers.

Gigabyte designs the R-Series around serviceability and data centre operational discipline, integrating ASPEED AST2600 BMC management with IPMI, HTML5 KVM, and remote media to streamline provisioning and lifecycle control while aligning with modern security and authentication requirements.

Key Applications:

Virtualization hosts
Hybrid/private cloud compute nodes
Network function virtualization (NFV)
Edge infrastructure services
Mixed NVMe and legacy storage nodes

At Happyware - Server Hardware you benefit from non-binding offers tailored to your configuration of the R184-A90-AAJ1 Gigabyte and extended warranty options up to 6 years to secure long-term operational planning for enterprise rollouts.

Technical details of R184-A90-AAJ1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

BR (LGA 7529)

CPU Family:

Xeon 6

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon 6900 w/ P-cores Xeon 6 SoC

Supported CPU Generation:

6th

Supported CPU Codename:

Granite Rapids

Nodes:

RAM Type:

RDIMM MRDIMM

RAM Max. Total:

6TB

RAM Slots Total:

Memory Slots:

ECC:

ECC

Bays:

4x 3.5" HotSwap NVMe, SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

2x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

2x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps I350-AM2

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

USB Type-A LED Indicators

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

2000W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Power Supply Cooler:

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

500W

Applications:

Enterprise Applications Enterprise Server Networking Hybrid/Private Cloud Server

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

Pre-installed Components:

None

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Certificates:

80 Plus Titanium

Chassis Intrusion:

How long is the Warranty and how you can get technical support for R184-A90-AAJ1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
