R183-Z96-AAV1 Gigabyte
High-Density 1U Dual-Socket AMD EPYC SP5 Rack Server Barebone with the R183-Z96-AAV1 Gigabyte
The R183-Z96-AAV1 Gigabyte is a 1U rack server barebone engineered around the dual-socket AMD EPYC 9005/9004 (Turin/Genoa) SP5 platform, delivering up to 192 cores in a compact footprint with up to 400W TDP per CPU for sustained all-core throughput. Its 24-slot DDR5 RDIMM ECC memory architecture exposes 12 channels per CPU, enabling high bandwidth and capacity scaling up to 6TB for consolidation-heavy virtualization and memory-intensive middleware.
For I/O and expansion planning, the R183-Z96-AAV1 Gigabyte provides PCIe 5.0 connectivity through 2 x16 FHHL slots and 2 OCP NIC 3.0 PCIe 5.0 x16 connectors, supporting high-speed NICs, SmartNICs, and accelerators where needed. Storage is optimized for mixed media with 8 hot-swap front bays (4 flexible 3.5”/2.5” plus 4 x 2.5”) supporting NVMe and SATA, with SAS-4 enabled via an add-in HBA. Three onboard M.2 NVMe slots enable mirrored boot or dedicated cache tiers without consuming front bays.
Why Choose the R183-Z96-AAV1 Gigabyte?
The R183-Z96-AAV1 Gigabyte balances core density, memory channel bandwidth, and PCIe 5.0 expansion in a serviceable 1U chassis, making it a pragmatic building block for scale-out clusters and scale-up nodes alike. Redundant 1600W 80 PLUS Titanium PSUs, IPMI/HTML5 KVM management via an AST2600 BMC, and optional TPM 2.0 support align the platform with enterprise operational requirements and standardized security baselines.
Gigabyte designs the R183-Z96-AAV1 Gigabyte within its R-Series methodology, prioritizing predictable thermal behavior, tool-aware service access, and platform validation for continuous data center duty cycles, while maintaining compatibility with modern networking and storage fabrics.
Key Applications:
- Private and hybrid cloud virtualization clusters
- NFV, security, and routing appliances
- Database and in-memory middleware
- High-density scale-out compute
At Happyware - Server Hardware you benefit from non-binding offers tailored to your EPYC SP5 deployment plan and bulk order discount options for standardized rollouts of the R183-Z96-AAV1 Gigabyte across racks and sites.
