R183-Z94-AAV1 Gigabyte Dual EPYC 9005 1U 6NR183Z94DR000ACV1 Server Barebone

Get extra volume discount for 6NR183Z94DR000ACV1 and save cash:

Quantity	Unit price
	€3,440.00
To 4	€3,380.00 €3,440.00 (1.74% saved)
To 9	€3,310.00 €3,440.00 (3.78% saved)
From 10	€3,240.00 €3,440.00 (5.81% saved)

Product version:

Rev-3.x

Product line:

Gigabyte R Series

See all Rackmount Servers 1U

See other Gigabyte products

€3,440.00

Out of stock

Not available

Happyware Article Number:

SE8B6061-218116

Manufacturer Number:

6NR183Z94DR000ACV1

Brand:

Gigabyte

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R183-Z94-AAV1 Gigabyte

High-Density 1U Dual-Socket SP5 Rack Server Barebone optimized for Gen5 I/O with the R183-Z94-AAV1 Gigabyte

The R183-Z94-AAV1 Gigabyte is a 1U dual-socket SP5 platform designed for high core density and balanced I/O, supporting 2x AMD EPYC 9005/9004 processors for consolidated compute in private cloud and edge clusters. Its DDR5 RDIMM architecture scales across 24 DIMMs with 12 memory channels per CPU, enabling high-bandwidth virtualization footprints and large in-memory datasets while maintaining predictable NUMA behavior for multi-tenant workloads.

To eliminate storage bottlenecks, the R183-Z94-AAV1 Gigabyte integrates a front 12-bay hot-swap design supporting PCIe Gen5 NVMe, plus SATA and SAS-4 tiers when an optional controller is deployed. Expansion is aligned to modern fabrics, with PCIe 5.0 x16 slots for accelerator-class cards and dual OCP NIC 3.0 PCIe Gen5 interfaces for low-latency networking, while dedicated BMC management and IPMI/HTML5 KVM streamline remote operations at scale.

Why Choose the R183-Z94-AAV1 Gigabyte?

The R183-Z94-AAV1 Gigabyte delivers a strong density-to-performance ratio in 1U by combining SP5 compute scalability with Gen5 storage and network pathways, making it suitable for standardized rack deployments where power, cabling, and serviceability are constrained. Redundant hot-swap power, tool-less front access, and modular I/O options support phased growth from virtualization to storage-heavy compute without redesigning the node profile.

Gigabyte engineers this platform with an enterprise-first focus on serviceability, consistent firmware behavior, and component interoperability that aligns with data centre standards. The management stack based on ASPEED AST2600 BMC, UEFI, and dedicated management networking helps operations teams enforce lifecycle control, automation, and secure remote access across fleets.

Key Applications:

Hybrid and private cloud virtualization
High-density consolidated compute
NVMe storage-heavy compute tiers
Low-latency edge and networking services
Software-defined storage and HCI nodes

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your rollout plan for the R183-Z94-AAV1 Gigabyte, enabling fast procurement alignment with CPU, memory, and I/O configuration requirements, and you can extend the warranty up to 6 years to secure long-term availability for enterprise operations.

Technical details of R183-Z94-AAV1 Gigabyte

Type: Rack

Suitability: Server

CPU Socket: SP5 (LGA 6096)

CPU Family: EPYC

Supported CPU Manufacturer: AMD

Supported CPU Type: EPYC 9004, EPYC 9005

Supported CPU Generation: 4th, 5th

Supported CPU Codename: Genoa, Turin

Nodes: 1

RAM Type: RDIMM

RAM Max. Total: 6TB

RAM Slots Total: 24

Bays: 12x 2.5" HotSwap NVMe, SATA, SAS

Hot-Swap: Yes

RAID Support: Yes

PCIe: 2x PCIe 5.0 x16 (x16 mode)

Expansion Slots: 2x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN: 2x RJ45 1 Gbps Intel I350-AM2

Onboard Network LAN Speed: 1 Gbps

Front I/O Ports: System status LED, Storage Activity LED, LAN Activity LED, Power button with LED, System Reset button, USB, UID button with LED

IPMI / BMC integrated: Yes

Chipset: System-on-Chip (SoC)

Power Supply Wattage: 1600W

Redundant Power Supply: Yes

Number of Power Supplies: 2

80 Plus Certificate: 80 Plus Titanium

Quantity of Cooler: 8

Performance Class: Enterprise-Class

TDP (Thermal Design Power): 400W

Applications: Cloud Computing, Networking, Hybrid/Private Cloud Server, Enterprise

Onboard CPU: No

Onboard Graphic: Aspeed AST2600

Graphics Manufacturer: ASpeed

Pre-installed Software: ASPEED AST2600 Baseboard Management Controller (BMC), GIGABYTE Management Console web interface

Chassis Intrusion: No

OS: Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, Windows Server

Operating Temperature: 10°C to 35°C

Non Operating Temperature: -40°C to 60°C

Operating Relative Humidity: 8°C to 80°C

Non-operating Relative Humidity: 20°C to 95°C

How long is the Warranty and how you can get technical support for R183-Z94-AAV1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
